Semi Auto Tapping M/C (Heavy Duty Type)
Model Name
UTT-2C
Series
Component Production Line
Data
UTT-2C
Manufacturer information
provider logo
Union Tech

Automotive filter equipment manufacturer, Union Tech, Seaming, Tapping, Clipping

Problem with product info?
Update request
Manufacturer
Union Tech
Brand
-
SKU
33716
Product Name
Semi Auto Tapping M/C (Heavy Duty Type)
Model Name
UTT-2C
Size
-
Weight
-
Product Details

Union Tech Semi Auto Tapping M/C (Heavy Duty Type) UTT-2C

GENERAL DESCRIPTION

ㆍProduct capacity : 15~20 pcs/ min

ㆍTapping Type : 2 Spindle

ㆍAvailable Tap Size : MAX. M36

ㆍAvailable Tap angle tolerance : Less 0.25mm

ㆍMachine Dimention : W1150 x L3000 x H1500

FEATURE

ㆍServo chain feeding type(with special gear part)

ㆍ2 spindle multy head type designed for compact size & mass product

ㆍPLC controll progrem system is easy to operation

ㆍSpecial designed pushing device during the tapping to make a perfect rectangular of Bottom plate

ㆍOne touch type tooling change device(Collect Chuck 15mm & 20mm) installed

ㆍProduct count device installed

OPTION

ㆍ1) Special Forming Tap : Refer to attached OSG Tap spec.

Union Tech
Automotive filter equipment manufacturer, Union Tech, Seaming, Tapping, Clipping
Union Tech machines are designed with the highest quality for continued performance in the most demanding of environments. Companies worldwide have embraced the concepts and technologies pioneered by Union Tech, and our machines are now in operation in more than 25 countries around the globe. We appreciate your kind attention to Union Tech which has done systematic study and has made incessant endeavor to produce the safest and the most convenient equipment for the customers, based ton technology and know-how accumulated over the twenty six years since work in filter industrial. With confidence we can assure you that Union Tech will be a dependable partner of promising future and development of your company through strict quality management, fast and exact after service, and far advanced technology for customer’s convenience and satisfaction, and the craftsmanship for the utmost results.
