Power |
Main : 24 VAC/VDC Aux : 12VDC (Option, Spare power) |
||
|
Input |
DI : on/off, defrost input AI : temp. sensor (Thermistor), Pressure sensor /external (4~20mA) |
||
|
Output |
DO : alarm output (relay C contact, 250VA 3A) |
||
|
Motor |
EEV control output (Unipolar/BIpolar) |
||
|
Comm. |
RS-485 1ch, (MODBUS RTU) (option) |
||
|
Circumstance |
-20℃~70℃(5~95%, non-condensate) |
||
|
Storage |
-30℃~80℃(5~95%, non-condensate) |
||
|
Refrigerant |
R22, R134A, R404A, R407C, R410A, R507, R452A, R452B, R502, To be added |
||
FEATURES
Superheat controller of refrigeration cycle. 전Controls open rate of electronic expansion valve for efficiency and prevent of misoperation.
DIMENSIONS
DISPLAY
