FEATURES
Applicable to dehumidifier that is using to prevent rusting, sweating for pharmaceutical, chemical industry, plant, marine, precision electronics, food, cold storage, museum, plastic injection.
DIMENSIONS
SPECIFICATION
|
POWER |
Supply |
100-240VAC 50/60Hz |
||
|
MICOM |
MCU |
ATmega2560 |
||
|
DI |
Input port |
16 points(24VDC) / 1point(220VAC) |
||
|
Power |
None |
|||
|
DO |
Output port |
16 points / 1point(SSR) |
||
|
Method |
릴레이 접점 / PWM |
|||
|
Relay |
250V 3A / 24VDC |
|||
|
AI |
Sensors |
4ch(PT100Ω) / 2ch(0-3VDC) |
||
|
Humidity |
1ch(압력 or 온도) |
|||
|
CT |
1ch |
|||
|
AO |
Output port |
4ch(4-20mA or 0-10VDC) |
||
|
Load resistance |
4-20mA 출력시 500Ω |
|||
|
Comm. |
Port |
4ch |
||
|
Address |
1 ~ 99 |
|||
|
Baudrate |
9600, 19200bps |
|||
|
Parity bit |
None |
|||
|
Stop bit |
1 bit |
|||
|
Distance |
1.2km |
|||
|
Protocol |
MODBUS(2ch), Seungil(2ch) |
|||
|
RTC |
Schedule |
Daily, weekly, monthly |
||
|
Circu. |
Operation |
-20~70℃, 5~95%(Non-condensate) |
||
|
Storage |
-30~80℃ |
|||
