Convenient for accelerating or decelerating working speed or 3 dimensional parabolic operation thanks to manual operation in “All-Air” method with Auto Air Balance
Product features
– Noise is minimized by using compressed air only with no electricity.
– Device can be moved in the 3-dimensional arc direction and working speed can be adjusted to suit the movement of the personnel.
– Work precision can be ensured as there is no abrupt swinging or vibration.
– Simple circuit structure enables accurate functioning of all features while minimal downtime and easy part supply are ensured.
– The force required for using the device is only 2~5% of the manual work, and device can be used by virtually anyone.
– The device can be used efficiently by installing on the wall or ceiling.
Specifications
| MODEL | Allowed weight (kg) |
Dimension (mm) | Product weight (kg) |
||||
|---|---|---|---|---|---|---|---|
| Product height (Body) |
Work area |
Drop point |
Fixing plate |
Stroke | |||
| SAW-75 | 75 | 2170 | 2400 | 500 | 600 | 1400 | 160 |
| SAW-100 | 100 | 2170 | 2400 | 500 | 600 | 1400 | 190 |
| SAW-150 | 150 | 2170 | 2400 | 500 | 600 | 1400 | 220 |
| SAW-200 | 200 | 2170 | 2400 | 500 | 600 | 1400 | 260 |
| SAW-250 | 250 | 2170 | 2400 | 500 | 600 | 1400 | 360 |
Installation example
