Magplus, The Republic of Korea - Komachine Supplier Profile and Product List

- A specialized company in high-speed motor applications and high-power conditioning systems. A developer and manufacturer of turbo refrigerant compressors, turbo blowers, magnetic bearings, and high-speed PMSM devices. An industrial refrigeration and freezing equipment manufacturer, registered as a venture company. A company focusing its capabilities on both civilian and defense industries.A specialized company in high-speed motor applications and high-power conditioning systems. A developer and manufacturer of turbo refrigerant compressors, turbo blowers, magnetic bearings, and high-speed PMSM devices. An industrial refrigeration and freezing equipment manufacturer, registered as a venture company. A company focusing its capabilities on both civilian and defense industries.
- Turbo Refrigerant Compressor: Models MRC-200 and MRC-500 available. Offering a wide operating range through optimized 2-stage centrifugal compression design and variable speed PM motor with IGV control. An oil-free system utilizing magnetic bearings for zero wear and reduced maintenance costs. A vertical rotor system achieving very low power consumption by canceling out rotor weight from thrust load. A high-efficiency compressor with a compact and lightweight structure compared to conventional screw compressors. MRC-200 uses R134a refrigerant, with a 500RT model currently under development. Developing oil-free turbo refrigerant compressors for eco-friendly HFO refrigerants (R-1233zd(E)) as a national project. Providing refrigeration capacity ranging from 200 to 500 tons.Turbo Refrigerant Compressor: Models MRC-200 and MRC-500 available. Offering a wide operating range through optimized 2-stage centrifugal compression design and variable speed PM motor with IGV control. An oil-free system utilizing magnetic bearings for zero wear and reduced maintenance costs. A vertical rotor system achieving very low power consumption by canceling out rotor weight from thrust load. A high-efficiency compressor with a compact and lightweight structure compared to conventional screw compressors. MRC-200 uses R134a refrigerant, with a 500RT model currently under development. Developing oil-free turbo refrigerant compressors for eco-friendly HFO refrigerants (R-1233zd(E)) as a national project. Providing refrigeration capacity ranging from 200 to 500 tons.
- Magplus Turbo Blower: MLB model with 50HP 0.6Bar specifications.Magplus Turbo Blower: MLB model with 50HP 0.6Bar specifications.
- Power Conditioning Unit (PCU): A DC/DC converter, supplying 29Vdc to an aerial vehicle from a variable high voltage source generated by a PM generator mounted on a Turbo Fan Engine. A product conforming to military standards such as MIL-STD-461D and MIL-STD-810F.Power Conditioning Unit (PCU): A DC/DC converter, supplying 29Vdc to an aerial vehicle from a variable high voltage source generated by a PM generator mounted on a Turbo Fan Engine. A product conforming to military standards such as MIL-STD-461D and MIL-STD-810F.
- Vector Drive for Marine Vessels: VDM series developed as induction motor drives for pumps and fans for DSME's Jangbogo-III submarines. Providing power ranging from 10kW to 60kW, meeting marine and military standards including IEC 60092-504, IEC 61000-4-5, MIL-STD-461F, MIL-STD-740, MIL-STD-901D, and IP44.Vector Drive for Marine Vessels: VDM series developed as induction motor drives for pumps and fans for DSME's Jangbogo-III submarines. Providing power ranging from 10kW to 60kW, meeting marine and military standards including IEC 60092-504, IEC 61000-4-5, MIL-STD-461F, MIL-STD-740, MIL-STD-901D, and IP44.
- PCU & PM Generator for UCAV: A system where a PM generator directly connected to a gas turbine axis produces AC power, which is then supplied to the PCU for low voltage DC distribution to system loads.PCU & PM Generator for UCAV: A system where a PM generator directly connected to a gas turbine axis produces AC power, which is then supplied to the PCU for low voltage DC distribution to system loads.
- Magnetic Bearings and High-speed PMSM Drive Technology: Key technologies enabling oil-free, low-friction, and high-speed operation. Direct Drive System (DDS) technology for lighter weight, faster speed, and higher efficiency.Magnetic Bearings and High-speed PMSM Drive Technology: Key technologies enabling oil-free, low-friction, and high-speed operation. Direct Drive System (DDS) technology for lighter weight, faster speed, and higher efficiency.
- Advanced Magnetic Bearings and Oil-Free Systems: Non-contact operation without friction, resulting in no wear and reduced maintenance costs. A core technology contributing to extended equipment lifespan and a clean operating environment.Advanced Magnetic Bearings and Oil-Free Systems: Non-contact operation without friction, resulting in no wear and reduced maintenance costs. A core technology contributing to extended equipment lifespan and a clean operating environment.
- High Efficiency and Wide Operating Range: Achieving excellent part-load efficiency through optimized 2-stage centrifugal compression design and variable speed Permanent Magnet (PM) motor with Inlet Guide Vane (IGV) control. The ability to maintain optimal performance across diverse operating conditions.High Efficiency and Wide Operating Range: Achieving excellent part-load efficiency through optimized 2-stage centrifugal compression design and variable speed Permanent Magnet (PM) motor with Inlet Guide Vane (IGV) control. The ability to maintain optimal performance across diverse operating conditions.
- Compactness and Lightweight Design: A smaller footprint and less than 20% the weight compared to conventional screw compressors, maximizing space efficiency. A strength that enhances installation flexibility and reduces overall system size.Compactness and Lightweight Design: A smaller footprint and less than 20% the weight compared to conventional screw compressors, maximizing space efficiency. A strength that enhances installation flexibility and reduces overall system size.
- Domestic Technology and Customized Development Capabilities: Development of most core components, including magnetic bearings, high-speed inverters, and compressor controllers, using purely domestic technology. Flexible response capabilities to custom-develop products according to specific requirements of refrigeration equipment manufacturers.Domestic Technology and Customized Development Capabilities: Development of most core components, including magnetic bearings, high-speed inverters, and compressor controllers, using purely domestic technology. Flexible response capabilities to custom-develop products according to specific requirements of refrigeration equipment manufacturers.
- Compliance with Military Standards and Reliability: Marine vessel vector drives and PCU products meeting stringent military and industrial standards such as MIL-STD-901D and MIL-STD-461F. A factor ensuring high reliability and stable operation in extreme environments.Compliance with Military Standards and Reliability: Marine vessel vector drives and PCU products meeting stringent military and industrial standards such as MIL-STD-901D and MIL-STD-461F. A factor ensuring high reliability and stable operation in extreme environments.
- HVAC (Heating, Ventilation, Air Conditioning) SystemsHVAC (Heating, Ventilation, Air Conditioning) Systems
- Industrial Heat Pumps and Refrigeration ProcessesIndustrial Heat Pumps and Refrigeration Processes
- Marine Vessels and Submarines (Pump and Fan Drive Systems)Marine Vessels and Submarines (Pump and Fan Drive Systems)
- Defense and Aerospace (Power Systems for Unmanned Combat Aerial Vehicles - UCAV)Defense and Aerospace (Power Systems for Unmanned Combat Aerial Vehicles - UCAV)
- Industrial Refrigeration and Freezing Equipment ManufacturingIndustrial Refrigeration and Freezing Equipment Manufacturing
- Microturbine and Turbomolecular Pump Related FieldsMicroturbine and Turbomolecular Pump Related Fields
- China (preparing for market entry)China (preparing for market entry)
- PCU products comply with military standards such as MIL-STD-461D and MIL-STD-810F.PCU products comply with military standards such as MIL-STD-461D and MIL-STD-810F.
- Vector Drives for Marine Vessels meet marine and military standards including IEC 60092-504, IEC 61000-4-5, MIL-STD-461F, MIL-STD-740, MIL-STD-901D, and IP44.Vector Drives for Marine Vessels meet marine and military standards including IEC 60092-504, IEC 61000-4-5, MIL-STD-461F, MIL-STD-740, MIL-STD-901D, and IP44.
- Capability in designing and manufacturing high-efficiency, oil-free compressors based on magnetic bearing and high-speed PMSM drive technologies.Capability in designing and manufacturing high-efficiency, oil-free compressors based on magnetic bearing and high-speed PMSM drive technologies.
- Currently developing oil-free turbo refrigerant compressor technology for eco-friendly HFO refrigerants through a national R&D project.Currently developing oil-free turbo refrigerant compressor technology for eco-friendly HFO refrigerants through a national R&D project.
