Power Conditioning Unit (PCU)
Model Name
-
Data
-
Manufacturer information
provider logo
MagplusTurbo refrigerant compressor, Turbo compressor / device, Magnetic bearing, PMSM device
Problem with product info?
Update request
Manufacturer
Magplus
Brand
-
SKU
45164
Product Name
Power Conditioning Unit (PCU)
Model Name
-
Size
-
Weight
-
Product Details

PCU for PM generator

It mainly supplies 29Vdc of 120A to an aerial vehicle.



Main features

Low noise (Load sharinig)

High efficiency (ZVS)

Dynamic load capability (1MHz)

Compact design (Contact cooling)

Satisfied MIL-STD-704, 461D, 810E

MagplusTurbo refrigerant compressor, Turbo compressor / device, Magnetic bearing, PMSM device
We, Magplus, are specialized on designing and fabrication of high-speed motor applications and high-power conditioning systems, such as axial turbo fan, turbo compressor/blower, magnetic bearings and high speed PMSM drives. They are called DDS(Direct Drive System) that concerns with the demand of lighter in weight, faster in speed, and higher in efficiency. Based on the technology of design and test skills for high speed PMSM applications, we are ready to fulfill customer's satisfaction.
