Features
High traction power Heavy weight (5,495kg) and long wheelbase (2,751 mm) increase traction power. | Large Fuel Tank Get larger fuel tank size (300ℓ) for longer operation time and more convenience for fuel injection. | 4-pillar cabin The spacious 4-pillar cabin offers a clear 360° view of the full working width of attached implements. |
12Fx12R Synchro shuttle lever Synchro shuttle lever makes changing direction much easier. | Premium seat he air suspension seat provides comfort and the 10-/20-degree swiveling seat makes rear operation easier. | Standard air-conditioner The standard air-conditioning system ensures a comfortable work environment during hot days. |
High performance Large capacity hydraulic pump with high lift capacity increases productivity. | A wide field of vision The hood design combined with a large windshield provides a wide field of view with minimal obstructions. |
Specification
| Category | LS1104 | LS1204 | LS1304 | LS1404 | |
| Dimensions& Weight | Overall length, Bumper to link (mm) | 4969 | |||
|---|---|---|---|---|---|
| Overall width with tires (mm) | 2323 | ||||
| Wheelbase (mm) | 2751 | ||||
| Overall height to top ROPS/Cab (mm) | 3089 | ||||
| Total weight without ballast (kg) | 5350 | 5350 | 5495 | 5495 | |
| Tires | Front | 14.9 - 28 | |||
| Rear | 18.4 - 38 | ||||
| PTO | Type | Independent/GSP | |||
| Rear (rpm) | 540/1000 or 540/750 | ||||
| Hydraulic | Control system | Position / Draft | |||
| Implement pump (lpm) | 70.6 | ||||
| Category, 3 pt hitch | CAT Ⅱ | ||||
| Hitch lift capacity, Link end (kgf) | 3619 | ||||
| Remote ports | 6(front), 4/6(rear) | ||||
| Engine | |||||
| Type | 4-Stroke, direct-injection, Water-cooled | ||||
| Model | LR6A3LU22/0810E | LR6A3LU22/0882E | LR6A3LU22/0956E | LR6A3LU22/0810E | |
| Emission | Stage III | ||||
| Engine Hp (kW) | 108.6(81) | 118.3(88.2) | 128.2(95.6) | 138.1(103) | |
| PTO HP | 92.3 | 100.5 | 109 | 117.4 | |
| Rated speed (rpm) | 2200 | ||||
| Displacement (cc) | 6490 | ||||
| Fuel tank capacity(L) | 250 | 300 | |||
| Traveling system | Transmission Type (options) | Synchro Shuttle | |||
| No. of speed | F12 x R12 | ||||
| Forward Speed (Km/h) | 2.0~34.2 | ||||
