Product Name Remote Controller
Model None
Series Remote Controller
Catalog
Product Description

Features

1. Battery replacement cycle increasing by designing a low effort.
2. Streamlined shape design and miniaturization transmitter.
3. Applying strong nylon glass on impact for enhanced reliability.
4. Providing convenience to apply a mode selector switch.
5. MSIP-CRM-KGO-KG-R12MLHCCC
    MSIP-CRM-KGO-KG-R08AAA


Performance

ListTransmitterReceiver
Frequency range447.6000 ~ 447.9875 Mhz
447.6000 ~ 447.9875 Mhz
Rated Voltage08R : DC3V / 12R : DC6V90C ~ 240V AC /50 ~ 60 Hz
Size
08R : 150mm X 52mm X 41mm
12R : 230mm X 56mm X 49mm
08R / 12R : 230mm X 56mm X 70mm
Electric Power antenna10mW10mW
Oscillation methodPLLPLL
Modulation systemGFSK(F1D)GFSK(F1D)
Method of communicationsSimplexSimplex
Transmission speed2400bps2400bps
Frequency stability2ppm 이하2ppm 이하
Channel number32ch32ch
Channel separation12.5khz12.5khz
Bandwidth8.5khz 이하8.5khz이하
Usual temperature-20℃ ~ +60℃이하
-20℃ ~ +60℃이하
Cable
K60227 IEC7 300/500V 0.75SQ 16/23C (1.7M)
Transmitting distanceNo obstacle 130MNo obstacle 130M



REMOTE CONTROLLER

ModelKG-R08 SERIESKG-R12 SERIES








Function

ㆍE-STOP

ㆍSelector ON/OFF switch

ㆍBattery : AA1.5V 2ea

ㆍE-STOP

ㆍSelector ON/OFF switch

ㆍMode selection function Selector switch
   AUX-MAIN, LIGHT, A A+B B

ㆍButton : F1(HORN), F2

ㆍBattery : AA1.5V 4ea




Product Function

Receiver

▶ KG-R12P MODEL

Transmitter

▶ KG-R08P MODEL



Name composition




External form / Drawing

KG-R08AAA / KG-R08AAA(D)



KG-R08AAA(T)



KG-R12MLHAAA



Accessory

KG-R200


Transmitter Hand Band

KG-R300 / R400

Transmitter shock protection guard

G-R500 / R600

Transmitter vinyl cover




Connection diagram

KG-R08(D) 12/24V DC

KG-R08 110/220V AC

KG-R12 SERIES


KG-R08(T) SERIES (Remocon & pendant connection diagram)


Basic Used And Precautions

1. Turn off the emergency switch.
2. Turn the green selector switch on the bottom of the transmitter turned ON by pressing any button will power ON.
     If the receiver can be operated lamp lighting completed.
3. Press the any button for operation
4. After use, the bottom of the green selector switch on the transmitter left OFF when stored.
5. If the battery power indicator lights up on the cases(BAT), replace the electrical (AA 1.5V).
    (If not in use should be kept as an emergency switch OFF, you can prevent battery discharge.)


Safety information
Before using this product, Please read the safety information.

Danger
1. Be sure to turn off power before connection wires or changing bulb, it can cause electric shock.
2. Product installation can be sure only qualified personnel precautions. according to a safety precautions.

Warring
1. Please check for the correct connection wire before installing it. Incorrect wiring will cause a break down of product.
2. Please check for the correct voltage, Over voltage will cause by malfunction of product.

Caution
1. This product is only suitable for indoor use.
2. Applying a strong shock on the outside of product may cause break down.
3. Please refer to the "wiring diagram" when you wire the product.
4. Please be cautions that contact with chemical such as thinner or benzene can cause of deformation of the product or color of change.
5. The contents of this manual may be changed without prior notification.
