High Performance T/C
Model Name
L160A | L160MA
Series
CNC Turning Center
Data
-
Manufacturer information
provider logo
HYUNDAI WIAAutomotive parts, Machine tools, Industrial machinery, Defense, Satellite, Aircraft components, Products R&D and more
Problem with product info?
Update request
Manufacturer
HYUNDAI WIA
Brand
-
SKU
13832
Product Name
High Performance T/C
Model Name
L160A | L160MA
Size
-
Weight
-
Product Details

Features

Fast and efficient machine to maximize productivity.

Superior machine structure to produce various products.

Angular contact ball bearings to maintain high-rigidity and low thermal distortion.

High rigidity through intensive finite element analysis

6" sub-spindle expands cutting capacity and capability (optional)

Rigid BMT Turret for heavy cutting (machine equipped with live tools)



Specifications

Description Unit L160A L160MA
Max Turning Dia mm 355 310
Max Turning Length mm 460 388
Chuck Size inch 6″ 6″
Driving Method - Belt Belt
Spindle RPM r/min 6,000 6,000
Spindle Output kw 11/7.5 11/7.5
Spindle Torque N.m 70/48 70/48
Travel(X/Z) mm 220/460 220/400
Rapid Travel(X/Z) m/min 36/36 36/36
Slide Type - LM LM
No. of Tools EA 12 12
Tool Size mm 25/40 25/40
Milling Tool Speed r/min - 5,000
CNC - H/W FANUC i H/W FANUC i
HYUNDAI WIAAutomotive parts, Machine tools, Industrial machinery, Defense, Satellite, Aircraft components, Products R&D and more
HYUNDAI WIA has been a proud leader of Korea’s machine industry sector ever since the company’s establishment in 1976. Our wide range of products from key automotive components to machine tools, industrial Machinery, machinery equipment and aircraft components are the results of our advanced technology and years of accumulated know-how and experience, which we have developed over the years based on our principle, “Quality First." Today, HYUNDAI WIA has achieved world-wide recognition as a global brand and we promise to perform our role as a ‘Global Top Maker’ through a creative and challenging approach. Working to achieve technological development and investing in the training and education of our employees to establish a foundation for management stability.
