The characteristics FCP series spray dryer
Dongjin FCP Series spray dryer is designed suitable for drying various organic/inorganic chemicals and food.
The angle of the cone in the drying chamber is set to 60 degrees against the powder that is harmful for fluidity, and an air sweeper is mounted basically to prevent the powder remaining in the chamber.
ㆍ Spary-Air Contact
As we adapted a co-current flow style that fits heat-sensitive products, there is no distortion due to the heat.
ㆍ BAG FILTER
It is the collecting equipment for the powder that remains after drying. It is for 100% collection of powder and prevention of contamination. Especially the NOMAX filter is used, which enables operation at temperature up to the 200 ℃.
ㆍ WET SCRUBBER
It is used for air pollution in stead of a bag filter when the powder contains moisture.
ㆍ AIR SWEEPER
It is to prevent the powder attached inner part of the wall from being exposed to high temperature for a long time.
AIR HEATER
Various kinds of heating equipment can be used according to the demand of customers and the characteristics of products as follows.
1. Indirect steam air heater
2. Indirect oil or gas heater
3. Direct oil or gas air heater
4. Electric air heater
5. Liquid phase air heater
BASIC SPECIFICATION
FOOD : tomatos, ginseng, dry milk, orange juice, eggs, carrots, baby foods, enzyme, coffee, glucose, starch, instant tea, flour, fish meal, dextran
PHARMACEUTICAL PRODUCTS : Vitamines, penicillin, lysine (amino acids), streptomicine, yeast
CHEMICALS : detergent, white carbon, catalyst, insectcide, sodium phosphate, luminous materials, bentonite, graphite, chlorophyl products, citric acid, aromatic materials, zeolit
CERAMIC : alumina, ferrite, tile, piezoelectric, steatite, SiC,kaolin
DYE STUFFS AND PIGMENTS : ceramic pigments, ink, titanium dioxide, kaolin clay, zinc chromate, iron oxide, cosmetic colours
