DONG IN ELECTRIC

Non-automatic return switch for elevator

Model

Series

Non-automatic return Switch

Transaction Process

Please contact Komachine.

Payment

Please contact Komachine.

Delivery

Please contact Komachine.

Shipment

Please contact Komachine.

Origin

Please contact Komachine.

Description

If once contract has been detached and return it to original state, DI-104 is non -automatic return switch for elevator converting external force manually and it is used for two-way governor.

Features

TECHNICAL DATA
Contact resistant value	Less than 30mΩ
Thrust of contact point	Over 100gf/1 contact
Limit temperature	88℃
Rated voltage	DC 125V / AC 250V
Rated current	DC 1A / AC 15A

DIMENSION
Case width	61.7mm
Case depth	31.3mm
Case height	33.6mm
Normal roller stroke	3.0mm
Lever arm length	1.25mm
