Ergon COB HE Series
Flip-chip COB, the Ultimate Reliability
Features
- World’s 1st Silver-free Flip-chip, Higher Reflectivity
- No wire bonding, Better Robustness
- High Current Density for High lumen output and lm/$
- Lower Thermal Resistance, 40% higher LED Lifetime
- Better Current spreading, Lowest Droop
Applications
Specifications
| Model Number | Power(W) | Size (mm) | CRI(Ra) | Color Temp.(K) |
Rth(℃/W) |
Forward Current (mA. Typ / Max) | Lumen Output(lm) | Efficacy(lm/W) |
| ERC1507S830HE | 7.5 |
15.85×15.85×2.0(LES 8.9) |
80+ | 3,000 | 1.6 | 200 / 380 | 850 | 113 |
| ERC1507S850HE | 7.5 |
15.85×15.85×2.0(LES 8.9) |
80+ | 5,000 | 1.6 | 200 / 380 | 930 | 124 |
| ERC1812S830HE | 11.8 |
17.85×17.85×2.0(LES 12.0) |
80+ | 3,000 | 0.9 | 320 / 600 | 1,400 | 119 |
| ERC1812S850HE | 11.8 |
17.85×17.85×2.0(LES 12.0) |
80+ | 5,000 | 0.9 | 320 / 600 | 1,510 | 128 |
| ERC1820S830HE | 20.4 |
17.85×17.85×2.0(LES 12.0) |
80+ | 3,000 | 0.9 | 550 / 1,100 | 2,240 | 110 |
| ERC1820S850HE | 20.4 |
17.85×17.85×2.0(LES 12.0) |
80+ | 5,000 | 0.9 | 550 / 1,100 | 2,420 | 119 |
| ERC2530S830HE | 29.6 |
23.85×23.85×2.0(LES 19.0) |
80+ | 3,000 | 0.4 | 800 / 1,600 | 3,450 | 117 |
| ERC2530S850HE | 29.6 |
23.85×23.85×2.0(LES 19.0) |
80+ | 5,000 | 0.4 | 800 / 1,600 | 3,730 | 126 |
| ERC2540S830HE | 40.7 |
23.85×23.85×2.0(LES 19.0) |
80+ | 3,000 | 0.3 | 1,100 / 2,100 | 4,700 | 115 |
| ERC2540S850HE | 40.7 |
23.85×23.85×2.0(LES 19.0) |
80+ | 5,000 | 0.3 | 1,100 / 2,100 | 5,085 | 125 |
| ERC3050S830HE | 51.8 |
27.35×27.35×2.0(LES 23.0) |
80+ | 3,000 | 0.2 | 1,400 / 2,500 | 6,150 | 119 |
| ERC3050S850HE | 51.8 |
27.35×27.35×2.0(LES 23.0) |
80+ | 5,000 | 0.2 | 1,400 / 2,500 | 6,650 | 128 |
| ERC3070S830HE | 70.3 |
27.35×27.35×2.0(LES 23.0) |
80+ | 3,000 | 0.2 | 1,900 / 3,800 | 8,000 | 114 |
| ERC3070S850HE | 70.3 |
27.35×27.35×2.0(LES 23.0) |
80+ | 5,000 | 0.2 | 1,900 / 3,800 | 8,655 | 123 |
