1. Description
SIF/SIHF is a specialized silicone multi/single-core cable for use in high voltage and high strenghth extruded with silicone heat resistant rubber or whenever the insulation is subject to extreme temperature changes. SIF/SIHF cables are mainly found in steel producing industry as well as in cement, glass, ceramic factories and ship building,. SIF/SIHF cables are low-smoke and halogen-free especially suited for use in power plants. The silicone jacket provides added heat, chemical, oil and acidic resistance. Not permitted for outdoor use.
2. Application
- Wiring of Steel, cement, ceramic and iron works
- Power & Control cable(Heat Resistant / High voltage) for plants industry
- Bakery equipment and industrial furnaces
- Electric motor industry
- Sauna/solarium construction
- Thermal and heating elements
- Lighting technology
- Ventilator engineering
- Air-conditioning technology
- Galvanisation technology
3. Certification
UL approved : E120271 Silicone Jacket Cable
4. Cable Model
- SIF : Single conductor cable
- SIHF : Multi-conductor cable
- SIHF-SB : Multi-conductor cable with inner shield
- SIF-GL : SIF + Outer Glass Braiding
- SIHF-GL : SIHF + Outer Glass Braiding
- SIHF-P : SIHF + Outer Glass & metal Braiding
5. Cable Construction
| No. | Construction | Material |
| 1 | Conductor | Flexible tinned copper wire(IEC 60228, Class5) |
| 2 | Insulation | Heat Resistant of Silicone Rubber |
| 3 | Inner shield | Tinned copper wire |
| 4 | Out sheath | Heat Resistant of Silicone Rubber |
| 5 | Exterior | E-glass fiber or Glavanized steel wire.(option) |
Technical Data
| Physical and Chemical features | Continuous Temp. | -60 ~ 200℃ (Peak 230℃) |
| Excellent flexibility bending radius | Dia. Of cable X 15 | |
| Very good resistance of ambient heat shock | ||
| Flame Retardant properties and self-extinguish | ||
| Electric features | Standard voltage | 0.6/1.0 kv |
| Test voltage | 3000v / 5min | |
| Insulation resistance | above 200 MΏ/km | |
