Abrasive and Blasting Materials by WORLD BLAST - Komachine Supplier Profile and Product List

This product is manufactured by

WORLD BLAST

Home

Manufacturers

WORLD BLAST

Abrasive and Blasting Materials

TOP

Abrasive and Blasting Materials

Model Name

Series

Abrasive and Blasting Materials

View AllView All Series

Data

Manufacturer information

WORLD BLASTSanding machine, Shot machine, Air blast, Abrasive, Paint, Sanding toll processing, Nozzle

Problem with product info?

Update request

Manufacturer

WORLD BLAST

Brand

SKU

32123

Product Name

Abrasive and Blasting Materials

Model Name

Size

Weight

Product Details

WORLD BALST Abrasive and Blasting Materials

There is no debris on the surface after machining.Its surface gloss and surface roughness are constant and it does not break. Its lifetime is more than 60 times longer than glass bead and its life is more than 6 times longer than zirconium bead.
It is recognized as the best value as a blast material because the amount of dust is small and environmental wastes cost is low, working environment improves and abrasion of equipment parts is low.

Stainless steel shot, rust-proof, spherical.
WORLD BALST Abrasive and Blasting Materials 2

Chemical composition

Carbon (Max)	0.03 %	Manganese (Max)	2.0 %
Phosphorus(Max)	0.05 %	Sulfur (Max)	0.03 %
Silicon (Maximum)	1.0 %	Chromium	16.0~18.0 %
Nickel (Maximum)	10.0~14.0 %	Molybdenum	2.0~3.0 %

WORLD BALST Abrasive and Blasting Materials 3

Microstructure : Powder (BEAD)
WORLD BALST Abrasive and Blasting Materials 4

Hardness : 40 ~ 50 Hrc
WORLD BALST Abrasive and Blasting Materials 5

Apparent density : 7.9 g/㎤
WORLD BALST Abrasive and Blasting Materials 6

Size(mash) distribution

NO	MESH	MICRONS		MM
NO	SIZE	MAX	MIN	MAX	MIN
1	40 ~ 50	400	300	0.400	0.300
2	50 ~ 70	300	200	0.300	0.200
3	70 ~ 150	200	100	0.200	0.100
4	150 ~ 300	100	50	0.100	0.50
5	300 ~ 400	60	20	0.060	0.20
6	400 ~	20	-	0.020	~

Application

1) The Features of SUS BEAD
    ⓐ There is no debris on the surface after machining
    ⓑ Lifetime is 100 times of GLASS BEAD and 6 times of CERAMIC BEAD
    ⓒ Its surface gloss and surface roughness are constant and it does not break. Its lifetime.
    ⓓ Operation speed is fast and dust generation is extremely small. (1/70 of GLASS BEAD)
    ⓔ It does not cause scratches, and it is good for the upgrading and finishing of the product.

2) Economic feasibility of SUS BEAD
ⓐ Waste treatment costs are low because the working environment is clean and there is little dust.
ⓑ Wear rate is lower than other abrasives. Thus, the maintenance of the equipment and the life of the consumables are prolonged.

3) Uses of SUS BEAD

CLEANING		ⓐ Cleaning of various molds such as plastic, rubber, casting, glass, die casting, shell mold ⓑ Aircraft turbine blades, aircraft engine, automobile engine and various parts of carbon removal. ⓒ Repair of oil plant equipment ⓓ Removal of surface debris from stainless steel containers, heat treated metal parts.

DEBURR		ⓐ Gear parts, die casting parts, aircraft precision parts, automobile parts, press parts

PEENING		ⓐ Small springs, tools, turbine blades, gears, shafts, piston heads, bolts, nuts, screw parts. plastic ⓑ Thermosetting resins (melamine, phenol, epoxy, FRP) ⓒ Thermoplastic resin (nylon, PP, PVC, SAN, PBT, ABS) ⓓ Engineering plastics, Polycarbonate, PPO, Polyacetal

WORLD BALST Abrasive and Blasting Materials 7

WORLD BALST Abrasive and Blasting Materials 8

WORLD BLASTSanding machine, Shot machine, Air blast, Abrasive, Paint, Sanding toll processing, Nozzle

WORLD BLAST has developed the surface treatment technology and introduced and developed the advanced technology to the surface of all industrial fields from blast machine business department, new material business business department, surface treatment establishment, shot business department. In order to contribute to the processing market, we will continue to grow up to be a sincere company with honesty and cooperation with employees having joint vision to reach global companies in the blast surface treatment market. In addition, we will continue to research and develop the current blast machines and abrasives with various products and grow into a company that can stand proudly in the world market.
