Heating, Cooling, Temperature indicator, Digital temperature controlling device and more
|
Product connection |
Panel Punching Size |
Product Size
| Feature |
For cooling and freezing control (refrigerator) Sensor temperature correction Output delay function Defrost (auto mode – real-time/time cycle, manual mode) Defrost output(electric heater/hot gas) End of Defrost by temperature/timer Defrost linkage function Fan control output Automatic light control output Drain heater output Night Power saving funvtion Select celsius/fahrenheit display Upper and lower temperature settings and built-in alarm buzzer Alarm output delay Door open alarm Self-diagnosis function when sensor abnormalities Program lock function |
| Temperature range | -50.0 to 100.0℃ |
| Resolution | 0.1℃ |
| Output | On/Off Relay 6EA (3A) |
| Input sensor | NTC 5kΩ, 25℃ 2EA |
| Power Supply |
Trans External 12V AC/DC, 24V DC (Option) |
| Housing | ABS incombustibility grade V0 |
| Dimension | H80 x L38 x D81 (mm) |
