MODEL NO.

UINT

TK-80/40F

FORMING AREA & CUTTNG AREA

mm

MAX. 800W * 400L

FORMING DEPTH

mm

MAX. 150

CYCLE TIME

Sec.

4 ~ 8

MATERIAL THICKNESS

mm

0.3 ~ 2.0(PP, PS, PE, PSP, HIPS, ABS, PVC, BOPS, etc)

MATERIAL SHEET TRANSFER

AC SERVO MOTOR 1kw

MATERIAL SHEET WITDH CONTROL

AUTOMATIC SYSTEM BY GEARED MOTOR

HEATING

kw

TWO STEP CERAMIC HEATING(UPPER & LOWER SIDE)

VACUUM PUMP

HP

5

CUTTING SYSTEM

HYDRAULIC CYLINDER

STACKING SYSTEM

PNEUMATIC CYLINDER

POWER CONSUMPTION

kw

40

MACHINE SIZE

L * W * H(㎜)

10,000 * 2,500 * 2,400

WEIGHT

TON

8.0
