THERMONIK, The Republic of Korea - Komachine Supplier Profile and Product List

- A specialized manufacturer of high-temperature electric furnaces and special furnaces, supplying various industrial heat treatment equipment, including graphite furnaces, metal furnaces, and hot presses, to domestic and international markets based on technical cooperation with Japan.A specialized manufacturer of high-temperature electric furnaces and special furnaces, supplying various industrial heat treatment equipment, including graphite furnaces, metal furnaces, and hot presses, to domestic and international markets based on technical cooperation with Japan.
- The main product lines include graphite furnaces, metal furnaces, pressurized furnaces & Hot Presses, R&D furnaces, atmosphere furnaces, continuous furnaces, Box Type furnaces, Tube furnaces, Rotary Kilns, and special furnaces.The main product lines include graphite furnaces, metal furnaces, pressurized furnaces & Hot Presses, R&D furnaces, atmosphere furnaces, continuous furnaces, Box Type furnaces, Tube furnaces, Rotary Kilns, and special furnaces.
- Graphite furnaces offer ultra-high-temperature environments up to 2,800℃, with a maximum of 3,000℃, and low-oxygen atmosphere creation technology through an all-graphite internal construction.Graphite furnaces offer ultra-high-temperature environments up to 2,800℃, with a maximum of 3,000℃, and low-oxygen atmosphere creation technology through an all-graphite internal construction.
- Metal furnaces utilize metal materials like tungsten or molybdenum for heaters, insulation, and chamber walls, enabling high-temperature heat treatment up to 1,800℃ in ultra-pure environments.Metal furnaces utilize metal materials like tungsten or molybdenum for heaters, insulation, and chamber walls, enabling high-temperature heat treatment up to 1,800℃ in ultra-pure environments.
- The R&D graphite furnace (model TNGRD-200) is a research and development equipment with a heat zone of 200 Dia. x 130H and a maximum temperature specification of 2800℃ (peak 3000℃).The R&D graphite furnace (model TNGRD-200) is a research and development equipment with a heat zone of 200 Dia. x 130H and a maximum temperature specification of 2800℃ (peak 3000℃).
- The continuous round type furnace (model TNOST-7500) is a large-scale equipment capable of operating up to 2900℃ in a heat treatment area of 260 Dia. x 7500L.The continuous round type furnace (model TNOST-7500) is a large-scale equipment capable of operating up to 2900℃ in a heat treatment area of 260 Dia. x 7500L.
- The company possesses the technological capability to continuously develop and manufacture products tailored to diverse customer requirements.The company possesses the technological capability to continuously develop and manufacture products tailored to diverse customer requirements.
- Securing advanced technological capabilities through technical cooperation with Japan's Thermonic Co. Ltd., initiated in February 2001.Securing advanced technological capabilities through technical cooperation with Japan's Thermonic Co. Ltd., initiated in February 2001.
- Possession of multiple core patents, including continuous single-batch furnaces, tiltable continuous furnaces, multi-stage furnaces, sintering furnaces using heating rollers, and single crystal growth furnaces.Possession of multiple core patents, including continuous single-batch furnaces, tiltable continuous furnaces, multi-stage furnaces, sintering furnaces using heating rollers, and single crystal growth furnaces.
- Capability to achieve ultra-high-temperature environments up to 3,000℃ and control various atmospheres such as vacuum, inert gas, oxidizing, and reducing conditions.Capability to achieve ultra-high-temperature environments up to 3,000℃ and control various atmospheres such as vacuum, inert gas, oxidizing, and reducing conditions.
- Optimization technology for high-purity and high-crystallization processes, minimizing contamination through all-metal or all-graphite structures and enhancing the crystallinity of carbon materials.Optimization technology for high-purity and high-crystallization processes, minimizing contamination through all-metal or all-graphite structures and enhancing the crystallinity of carbon materials.
- Expertise in designing and manufacturing customized electric furnaces that meet specific customer requirements.Expertise in designing and manufacturing customized electric furnaces that meet specific customer requirements.
- Provision of customer support through experimental equipment at its Hwaseong factory, allowing customers to conduct tests before purchasing products.Provision of customer support through experimental equipment at its Hwaseong factory, allowing customers to conduct tests before purchasing products.
- Graphitization and carbonization processes for graphite sheets.Graphitization and carbonization processes for graphite sheets.
- Sintering of SiC (silicon carbide) products and C/C composite sintering industries.Sintering of SiC (silicon carbide) products and C/C composite sintering industries.
- Heat treatment of various products such as graphite powder.Heat treatment of various products such as graphite powder.
- Sintering and compositional testing of ceramics and ultra-high-melting-point metals like tungsten, tantalum, and molybdenum.Sintering and compositional testing of ceramics and ultra-high-melting-point metals like tungsten, tantalum, and molybdenum.
- Advanced industrial sectors requiring high-temperature heat treatment, such as semiconductors, new materials, and secondary batteries.Advanced industrial sectors requiring high-temperature heat treatment, such as semiconductors, new materials, and secondary batteries.
- Japan, Taiwan, China, VietnamJapan, Taiwan, China, Vietnam
- Germany, FranceGermany, France
- USAUSA
- Patent for continuous single-batch furnace.Patent for continuous single-batch furnace.
- Patent for tiltable continuous furnace.Patent for tiltable continuous furnace.
- Patent for multi-stage furnace.Patent for multi-stage furnace.
- Patent for sintering furnace using heating roller.Patent for sintering furnace using heating roller.
- Patent for single crystal growth furnace.Patent for single crystal growth furnace.
- Patent registration related to graphite heaters.Patent registration related to graphite heaters.
