Overview
- Summary
- SOPH is a specialized company established in 1998 with its headquarters in Germany, offering magnetic clamping and handling solutions through its brands BRISC (magnetic chucks), magbo (mold & die clamps), and HELMHOLTZ (lifting magnets).SOPH is a specialized company established in 1998 with its headquarters in Germany, offering magnetic clamping and handling solutions through its brands BRISC (magnetic chucks), magbo (mold & die clamps), and HELMHOLTZ (lifting magnets).
- Key Products/Technologies
- BRISC Magnetic Chucks: This product line includes permanent, electromagnetic, and electro-permanent magnetic chucks, utilized in various machining applications such as precision grinding, milling, turning, and electrical discharge machining (EDM, WEDM). The PMM model features a 4+11mm pole pitch, a maximum magnetic clamping force of up to 180 N/cm², a low flux depth of 6mm, and a coolant and waterproof structure. The EPS model is a fine-pitch electromagnetic chuck with a full metallic surface, 50x50mm square poles, and a magnetic force exceeding 200 kg per pole, incorporating electro-permanent magnetic technology to prevent deformation from temperature rise. BRISC AA/BB models are electro-permanent magnetic chucks for milling, offering high clamping forces, a magnetism elimination system, a durable waterproof surface, and integrated CUA-H/CUD-H control units.BRISC Magnetic Chucks: This product line includes permanent, electromagnetic, and electro-permanent magnetic chucks, utilized in various machining applications such as precision grinding, milling, turning, and electrical discharge machining (EDM, WEDM). The PMM model features a 4+11mm pole pitch, a maximum magnetic clamping force of up to 180 N/cm², a low flux depth of 6mm, and a coolant and waterproof structure. The EPS model is a fine-pitch electromagnetic chuck with a full metallic surface, 50x50mm square poles, and a magnetic force exceeding 200 kg per pole, incorporating electro-permanent magnetic technology to prevent deformation from temperature rise. BRISC AA/BB models are electro-permanent magnetic chucks for milling, offering high clamping forces, a magnetism elimination system, a durable waterproof surface, and integrated CUA-H/CUD-H control units.
- magbo Mold & Die Clamps: These electro-permanent magnetic systems are designed for quick mold changes in injection molding, blow molding, thermoforming, metal stamping, die casting, and rubber molding industries. The MBR model provides a service temperature of up to 250°C and uniform clamping force distribution across the entire mold surface, generating high power without residual magnetism through a special magnetic circuit. The MBP model boasts a force of 690 daN per pole, a 70mm pole size, 46mm magnet thickness, a maximum working temperature of 120°C, and a 20mm magnetic flux depth, integrating various safety and control features like real clamping force reading and mold slipping detection.magbo Mold & Die Clamps: These electro-permanent magnetic systems are designed for quick mold changes in injection molding, blow molding, thermoforming, metal stamping, die casting, and rubber molding industries. The MBR model provides a service temperature of up to 250°C and uniform clamping force distribution across the entire mold surface, generating high power without residual magnetism through a special magnetic circuit. The MBP model boasts a force of 690 daN per pole, a 70mm pole size, 46mm magnet thickness, a maximum working temperature of 120°C, and a 20mm magnetic flux depth, integrating various safety and control features like real clamping force reading and mold slipping detection.
- HELMHOLTZ Lifting Magnets: This comprehensive range of magnetic lifting solutions includes permanent, electro-permanent, pneumatically actuated permanent, battery-powered electro-permanent, and electromagnetic types. The NLT model is a pneumatically actuated permanent lifting magnet, featuring V-shaped pole shoes for handling both flat and round components and a removable lift eye. The HPB model is a battery-operated electro-permanent lifting magnet with radio remote control, offering a lifting capacity of 3300 lbs and incorporating the HSS (Helmholtz Safety System) for enhanced safety. The HPM 4/100 model is a multi-magnet lifter with a 22000 lbs lifting capacity, capable of safely handling steel plates with a minimum thickness of 0.20 inches.HELMHOLTZ Lifting Magnets: This comprehensive range of magnetic lifting solutions includes permanent, electro-permanent, pneumatically actuated permanent, battery-powered electro-permanent, and electromagnetic types. The NLT model is a pneumatically actuated permanent lifting magnet, featuring V-shaped pole shoes for handling both flat and round components and a removable lift eye. The HPB model is a battery-operated electro-permanent lifting magnet with radio remote control, offering a lifting capacity of 3300 lbs and incorporating the HSS (Helmholtz Safety System) for enhanced safety. The HPM 4/100 model is a multi-magnet lifter with a 22000 lbs lifting capacity, capable of safely handling steel plates with a minimum thickness of 0.20 inches.
- Core Advantages
- A comprehensive package provider of magnetic solutions encompassing workholding, mold & die clamping, and material handling.A comprehensive package provider of magnetic solutions encompassing workholding, mold & die clamping, and material handling.
- Extensive experience and technological expertise accumulated since 1998, enabling the development and delivery of innovative clamping solutions.Extensive experience and technological expertise accumulated since 1998, enabling the development and delivery of innovative clamping solutions.
- A strong global presence with headquarters in Germany and branches in the USA and China, ensuring a broad customer base across Europe, North America, and the Far East.A strong global presence with headquarters in Germany and branches in the USA and China, ensuring a broad customer base across Europe, North America, and the Far East.
- Maintenance of a large inventory of finished products, facilitating rapid product availability and flexibility in order processing.Maintenance of a large inventory of finished products, facilitating rapid product availability and flexibility in order processing.
- Provision of immediate technical support and customized solutions through continuously trained and highly skilled service and sales engineers.Provision of immediate technical support and customized solutions through continuously trained and highly skilled service and sales engineers.
- Implementation of electro-permanent magnetic technology, ensuring clamping force retention during power loss, elimination of residual magnetism, uniform clamping force, extended mold life, suitability for cleanroom environments, and eco-friendly technology.Implementation of electro-permanent magnetic technology, ensuring clamping force retention during power loss, elimination of residual magnetism, uniform clamping force, extended mold life, suitability for cleanroom environments, and eco-friendly technology.
- Integration of advanced safety features such as real clamping force reading, mold slipping detection, bottom dead center interlock, proximity sensors, current sensor systems, magnetic saturation systems, and the HSS safety system.Integration of advanced safety features such as real clamping force reading, mold slipping detection, bottom dead center interlock, proximity sensors, current sensor systems, magnetic saturation systems, and the HSS safety system.
- Target Industries
- Automotive Industry: Secure fastening and optimized production processes.Automotive Industry: Secure fastening and optimized production processes.
- Mechanical Engineering: High-precision and efficient process implementation.Mechanical Engineering: High-precision and efficient process implementation.
- Steel Industry: Precision machining and handling of steel materials.Steel Industry: Precision machining and handling of steel materials.
- Construction Industry: Efficient solutions for precise machining and material handling.Construction Industry: Efficient solutions for precise machining and material handling.
- Energy Industry: Reliable systems for production, maintenance, and long-lasting energy solutions.Energy Industry: Reliable systems for production, maintenance, and long-lasting energy solutions.
- Shipping & Offshore: Safe handling and reliable fastening for maritime applications.Shipping & Offshore: Safe handling and reliable fastening for maritime applications.
- Molds & Tools Manufacturing: Precision fastening and efficient processes for high-quality tool and mold making.Molds & Tools Manufacturing: Precision fastening and efficient processes for high-quality tool and mold making.
- Aerospace Industry: Precision machining of complex parts.Aerospace Industry: Precision machining of complex parts.
- Metal Working Factories and Steel Service Centers: Material handling and surface treatment.Metal Working Factories and Steel Service Centers: Material handling and surface treatment.
- Injection Molding, Blow Molding, Thermoforming, Metal Stamping, Die Casting, and Rubber Molding Industries: Quick mold change and die clamping solutions.Injection Molding, Blow Molding, Thermoforming, Metal Stamping, Die Casting, and Rubber Molding Industries: Quick mold change and die clamping solutions.
- Major Markets
- China, Far EastChina, Far East
- Germany (Headquarters), All Europe areaGermany (Headquarters), All Europe area
- USA, Colombia (exported by US branch)USA, Colombia (exported by US branch)
- Certifications/Patents
- SOPH holds its own designs, technologies, patents, know-how, and intellectual property rights.SOPH holds its own designs, technologies, patents, know-how, and intellectual property rights.
- magbo mold & die clamping systems offer machine interfaces compliant with international safety standards such as EUROMAP/SPI/JIS.magbo mold & die clamping systems offer machine interfaces compliant with international safety standards such as EUROMAP/SPI/JIS.
Introduction
Location
Im Löwenthal 4, 55268 Nieder-Olm, Germany
