Product Name
Model CM20
Series Kamglide Bush
Catalog Kamglide BUSH.pdf
Product Description

Specifications

About KAMGLIDE

 KAMGLIDE composite bearings(Wear rings) are composite materials with thermosetting resin impregnated with fabric and have excellent strength and durability compared with general thermoplastic materials. The characteristics of KAMGLIDE appear depending on the combination of different resins and fabrics with high strength and high thermal resistance. In addition, glass fibers are used for products that require special strength, and solid lubricants such as PTFE and graphite can be optionally added which is suitable for higher load and speed.



■ Material structure Woven aramid fabric-reinforced phenolic composite with graphite additions

■ Features High wear resistance, suitable for high temperature applications, excellent impact resistance, high load capacity, good chemical resistance

■ Operating conditions Dry, maintenance-free

■ Availability Tubes, cylinderical bushes, plates, machined parts

■ Typical usage Iron and steel industry, agricultural equipment, pump bearing, heavy transport



■ Properties





Density

[g/cm3]

 Compressive strength

[MPa]

Impact strength

[J/m]

Hardness

[HRM]

Thermal expansion

[10-5/℃]

Swell in water

[%]

Max. Temperature

[℃]

Max. Compression

[MPa]

Continuous

 Intermittent

Radial

Axial

 CM20

SOLTRI  CM20

 1.40

340

60

115

2~3

1.0

200

220

80

55
