Gas Insulated Switchgear (GIS)
Model Name
-
Series
Underground Line / Substation
View All
Data
-
Manufacturer information
provider logo
Shinsung Industrial Electric

Electronic parts manufacturer, Recloser, Circuit breaker, Switch and more

Problem with product info?
Update request
Manufacturer
Shinsung Industrial Electric
Product Type
Machine
Brand
-
SKU
36076
Product Name
Gas Insulated Switchgear (GIS)
Model Name
-
Size
-
Weight
-
Product Details

GENERAL FEATURES

- SF6 vacuum interrupter GIS

- Double bus bar system

- Electrically/mechanically type tested

- Circuit Breaker is specially designed for easy disconnection ensuring easy installation and easy maintenance

- Each bay is divided into functionally distinct gas compartments that allow live-line work.

- PT bay each consist of a busbar that can control double busbars at the same time.



TECHNICAL DATA

Rated Voltage 25.8 kV Making Time 5 Cycle
Rated Frequency 60 Hz Control Voltage 125 Vdc
Rated Current 2000 A / 600 A Electrical Life Class E2
Rated Short-time Current 25 kA (65 kAp) Cable Charge Interruption C2
Power Frequency Withstand Voltage 70 kV (77 kV) / 1 min. Mechanical Endurance Class M2
Lightning Impulse Withstand Voltage 150 kV (165 kV) BIL Applied Standard S1
Dimension 600(W) x 2500(H) x 2100(D) Rated Gas Pressure (20℃) 0.5 bar
