Vault door manufacturer, Safe-deposit box, Fireproof safe deposit box, For bank / home / Office
•Exterior view
All the outward are finished with stainless displaying magnificent view.
The nickel-chrome coated handle smoothly moves and is embossed with chic image.
• Locking device
Selecting 2 locks out of 3 locks to open the door basically contains re-locking device and tempered glass inside the door so that the door is automatically locked at external impacts.
Time Lock function is available for 2nd and 3rd safety.
• Lattice door
It is made of stainless and includes a separate key.
• Filling
Concrete, form cement, etc. complying to UL Vault Door.
• Optional
| - Time Lock | Upon requests 2 movement, 3 movement. |
| - Emergency Ventilation | Installed on the inside of the door. |
| - Alarm System | In case that someone is stuck in, alarm sound comes out along with lamp by pressing the button. |
| - Electric Control (Auto-Light) | Able to add on in the place equipped with electric facilities. Auto-light switch function. |
• Door
All the outward are of stainless finish and hinged to balance according to installation area.
• Protective Layer
Basically filled with concrete. Form cement or specific material for SHIN JIN UL Vault Door.
• Lock
3 dials are installed - password change is available up to 1,000,000 times.
The lock device has an auxiliary device made of tempered glass
(lock change is available upon requests)
| Model Name | SVD-2100 (Basic) | SVD-2100(Classic) |
| Overall frame size | H2186 x W1610 x D400 | H2200 x W1610 x D400 |
| Door size | H1970 x W1050 x D210 | H1970 x W1050 x D320 |
| Door opening size | H1950 x W995 | H1950 x W995 |
| Wall opening size | H2161 x W1570 | W2175 x W1570 |
| Weight | 800kg | 1800kg |
| Filling | Concrete (basic) | UL Class 1 material (Same as SVD-UL8801) |
(Weight before filling., tolerance +/- 5%)
• Exterior view
All the outward are of stainless finish and the hinge part has stainless cover to express simple and clean tone. The nickel-chrome coated handle smoothly moves and is embossed with chic image.
• Locking system
This integral locking device designed by SHIN JIN controls the latch using 5- layer safety device in case of external impacts.
• Filling
Concrete, form cement, etc. complying to UL Vault Door.
• Lattice door
It is made of stainless and includes a separate key.
• Door
All the outward are of stainless finish and hinged to balance according to installation area.
• Protective Layer
Basically filled with concrete. Form cement or specific material for SHIN JIN UL Vault Door.
• Lock
Re-numbering dial and Long Key Lock included, interlocking with built-in latching device to enhance the safety.
(Lock change is available upon requests.)
| Model name | SVD-1100 Type 1 |
| Overall size | H2020 x W1200 x D300 |
| Door size | H1850 x W900 x D170 |
| Door opening size | H1830 x W840 |
| Wall opening size | H1975 x W1160 |
| Weight | 650kg |
| Filling | Concrete (basic) |
(Weight before filling., tolerance +/- 5%)
• Exterior view
All the outward are of stainless finish and the hinge part has stainless cover to express simple and clean tone
The round handle, which is coated with nickel-chrome on the brass casting,
smoothly moves and is embossed with chic image.
• Locking system
Applied 3 dials. Since the door opens when the 2 dials are released,
it enables you to work though one dial is out of order.
4 relocking devices in the door are designed to lock the auxiliary latch in case of external impacts.
• Function and auxiliary device for safety.
Contains ventilator and alarm in case someone is stuck in as well as lamp signal.
• Optional
Stainless steel lattice door, Time Lock • Door
All the outward are of stainless finish and hinged specially designed to balance the door height.
• Filling
Using special alloy and high-strength concrete to withstand oxygen cutting, high-speed drill, hammer attack, as well as UL burglary test tools.
• Emergency ventilation
Supplying fresh air in case someone is stuck in the door.
• Alarm system
Alarming sound and lamp turned on by switch.
• Auto-Light
On-off the internal light in the vault door linked to opening and closing the vault door.
• Dial
3 Movement Dial - over 1,000,000 times of number change is available
for UL GROUP 1 or upper level. 2 out of 3 dials are released to enhance the user convenience.
| Model name | SVD-UL2500 |
| UL Class | Class 1 |
| Overall frame size | H2120 x W1300 x D330 |
| Door size | H1950 x W1000 x D252 |
| Opening size | H1922 x W914 |
| Wall opening size | H2095 x W1260 |
| Weight | 1200kg |
(Weight before filling., tolerance +/- 5%)
• Exterior view
All the outward are of stainless finish and the hinge part has stainless cover to express simple and clean tone. The nickel-chrome coated handle smoothly moves and is embossed with chic image.
• Locking system
SHIN JIN uses UL certified dial.
Installed 4 relocking devices interlocked with tempered glass, it is automatically locked in case of external impacts.
• Auxiliary device for safety.
Emergency ventilation, alarm system, auto-lamp.
• Optional
Stainless steel-finish lattice door and 3-Movement Time Lock UL Certified • Door
All the outward are of stainless finish and hinged to balance according to installation area.
• Protective Layer
Basically filled with concrete. Form cement or specific material for SHIN JIN UL Vault Door.
• Emergency ventilation
Supplying fresh air in case someone is stuck in the door.
• Alarm system
Alarming sound and lamp turned on by switch.
• Electric control
On-off the internal light in the vault door linked to opening and closing the vault door.
• Lock
2 combination dial (UL) are installed ? special alloy, tempered glass and relocking device provide additional safety.
| Model name | SVD-2300 | SVD-2400 |
| UL Class | Class M | Class 1 |
| Overall frame size | H2120 x W1300 x D260 | H2120 x W1300 x D330 |
| Door size | H1950 x W1000 x D173 | H1950 x W1000 x D252 |
| Opening size | H1922 x W914 | H1922 x W914 |
| Opening size | H2095 x W1260 | H2095 x W1260 |
| Weight | 870kg | 1200kg |
(Weight before filling., tolerance +/- 5%)
