Shinil SNC

Shinil SNC

Stone Grapple (Rotating Type)

Model

Series

Other Attachment


Transaction Process

Please contact the manufacturer/supplier.

Payment

Contact the manufacturer/supplier.

Delivery

Contact the manufacturer/supplier.

Shipment

Contact the manufacturer/supplier.

Origin

Korea (Republic of)


Description

Features

- Excellent Performance in carrying, Loading and unloading of rocks.

- Mighty Power of high-pressure cylinder and equipped with shock absorbing cushion device.

- More long lifetime due to its superior abrasion resistance and excellent hardness.

- Equipped with swing bearing to absorb shock in collision.

- Including safety check valve to prevent the grabbed materials from falling down.



Specification

Description Unit TRSG50R TRSG140R TRSG220R TRSG350R
Operating Weight with Mount cap kg 365 850 1,960 2,100
lbs 805 1,874 4,320 4,630
Max.Opening Jaw width(A) mm 1,280 1,700 2,100 2,345
inch 50.40 66.93 82.68 92.32
Overall Height with Jaw(H1) mm 1,190 1,400 1,740 1,870
inch 46.85 55.12 68.50 73.62
Cylinder Oil Pressure bar 110 ~ 200 150 ~ 220 160 ~ 240 160 ~ 240
psi 1,595 ~ 2,900 2,175 ~ 3,190 2,320 ~ 3,480 2,320 ~ 3,480
Required oil flow ℓ/min 30 ~ 50 90 ~ 120 100 ~ 150 130 ~ 200
gpm 7.96 ~ 13.21 23.77 ~ 31.70 26.42 ~ 39.63 34.34 ~ 52.84
Cylinder setting pressure bar 250 260
psi 3,625.00 3,770.00
Max.Torque daNm 61 160 160 160
Rotating   Hyd.Rotating
Suitable Machine ton 4 ~ 7 9 ~ 13 18 ~ 22 28 ~ 32
lbs 8,818 ~ 15,432 19,841 ~ 28,660 39,682 ~ 48,500 61,728 ~ 70,546

* The above specifications are subject to change without prior notice for the quality enhancement.
