Description
SHN-3700/3800 is large size temperature/humidity indicator that accepts temp & humidity sensor input and displays engineering values and provides analog output.
ㆍIt displays temp/humidity simultaneously (Dual indicating)
ㆍTransformer isolation type.
ㆍ1 or 2 outputs are available from 1 input.
Product Detail
| SHN-3700 (벽걸이형) | ||||
| MODEL | INPUT1 | INPUT2 | OUTPUT | POWER |
|
700 : Wall Mounting (1단) |
Multi(mA ,V , mV ,Pt100Ω , T/C , 2-Wire) |
Multi(mA ,V , mV ,Pt100Ω , T/C , 2-Wire) |
1~5V (1단) |
AC 95V~250V |
|
700 : Panel Mounting (1단) |
4~20mA (1단) |
|||
|
800 : Wall Mounting (2단) |
1~5V/1~5V (2단) |
|||
|
4~20mA/4~20mA(2단) |
||||
|
2-Alarm(1단 ,2단) |
||||
Technical Data
| Model | SHN-3700 ,3800 Series | Function | Transmit DC signal in isolated conditon |
| Input | mA, RTD, 2-Wire, Potentiometer, T/C | Output | DC Siganl (4-20mA, 1-5V) Max : 2ch |
| Power | AC 95V~250V | Accuracy | 0.1% / Full scale |
| Display | LCD | Response Time | 0.5 sec (0~90%) |
| Front Adjustment | Zero and Span 5% | Weight | About 1.5kg / 2.0kg |
| Mounting | Wall mounting or Panel mounting | Dimensions(mm) |
SHN-3700 – W240 * H96 * D 151 Panel Cutting Size W230 * H82.8 * SHN-3800 -W350 * H250 * D 90 |
