Description
Basic Specifications
Rating Condition : Continuous
Voltage Endurance : AC1500V, 1Min.
Operating Temperature : 0~40℃
Coil Insulation Class : F Class (155℃)
Hall Effect Device : Optional
Power Supply Requirement : Trapezoidal or Sinusoidal 3-phase Brushless Amplifier
Performance Specifications
| Model | Unit | SWL-ePL20C | SWL-ePL30C | SWL-ePL40C | |
| Continuous | Force | [ N ] |
360 |
530 |
700 |
| Current | [ Arms ] |
6.7 |
6.7 |
6.7 |
|
| Max. | Force | [ N ] |
1015 |
1500 |
2000 |
| Current | [ Arms ] |
20.1 |
20.1 |
20.1 |
|
| Force Constant (Kf) | [ N/Arms ] |
54.3 |
79.5 |
105.7 |
|
| Back EMF Constant (Ke) | [ Vrms/(m/sec)] |
18.1 |
26.5 |
35 |
|
| Electrical Time Constant | [ msec ] |
5.08 |
5.44 |
5.57 |
|
| Resistance (L to L) | [ Ω ] |
2.77 |
3.94 |
5.2 |
|
| Inductance (L to L) | [ mH ] |
14.07 |
21.43 |
28.94 |
|
| Attraction Force | [ N ] |
1430 |
2140 |
2850 |
|
| Mover Weight | [ kg ] |
4.7 |
6.9 |
9.1 |
|
