SEWOO INDUSTRIAL SYSTEMS
SEWOO INDUSTRIAL SYSTEMS
Description
Basic Specifications
Rating Condition : Continuous
Voltage Endurance : AC1500V, 1Min.
Operating Temperature : 0~40℃
Coil Insulation Class : F Class (155℃)
Hall Effect Device : Optional
Power Supply Requirement : Trapezoidal or Sinusoidal 3-phase Brushless Amplifier
Performance Specifications
| Model | Unit | SWL-ePMI10C | SWL-ePMI20C | SWL-ePMI30C | SWL-ePMI40C | |
| Continuous | Force | [ N ] |
20 |
40 |
60 |
80 |
| Current | [ Arms ] |
1.5 |
1.5 |
1.5 |
1.5 |
|
| Max. | Force | [ N ] |
55 |
105 |
155 |
205 |
| Current | [ Arms ] |
4.5 |
4.5 |
4.5 |
4.5 |
|
| Force Constant (Kf) | [ N/Arms ] |
15 |
29 |
44.1 |
56.8 |
|
| Back EMF Constant (Ke) | [ Vrms/(m/sec)] |
5 |
9.7 |
14.7 |
18.9 |
|
| Electrical Time Constant | [ msec ] |
1.99 |
2.13 |
2.15 |
2.19 |
|
| Resistance (L to L) | [ Ω ] |
4.64 |
9.16 |
13.75 |
18.38 |
|
| Inductance (L to L) | [ mH ] |
9.24 |
19.53 |
29.5 |
40.2 |
|
| Attraction Force | [ N ] |
70 |
135 |
205 |
270 |
|
| Mover Weight | [ kg ] |
0.2 |
0.4 |
0.6 |
0.7 |
|
