Description
Basic Specifications
Rating Condition : Continuous
Voltage Endurance : AC1500V for 1 Min.
Insulation Resistance : DC500V, 10M
Operating Temperature : 10~40℃
Humidity : 20~80%
Coil Insulation Class : F Class (155℃)
Hall Effect Device : Optional
Power Supply Requirement : Trapezoidal or Sinusoidal Signal 3-phase Brushless Amplifier
Performance Specifications
| Model | Unit | SWL-PM30Y | SWL-PM50Y | SWL-PL50Y | SWL-TM20C | SWL-TG52G |
| Continuous Force | [ N ] | 256.7 | 718.5 | 910.5 | 179.5 | 2635 |
| Max. Force | [ N ] | 770.1 | 2155.5 | 2731.4 | 538.6 | 7905.0 |
| Continuous Current | [ Arms ] | 2.8 | 6.4 | 12.4 | 2.8 | 22.6 |
| Max. Current | [ Arms ] | 8.4 | 19.1 | 37.2 | 8.4 | 67.8 |
| Electrical Power | [ W ] | 528.8 | 1208.8 | 2342.0 | 528.8 | 4268.5 |
| Power Loss | [ W ] | 123.0 | 358.2 | 373.6 | 52.0 | 780.0 |
| Resistance (Line toLine) | [ Ω ] | 10.30 | 5.90 | 1.62 | 8.61 | 1.50 |
| Inductance (Line toLine) | [ mH ] | 34.80 | 70.00 | 14.79 | 8.37 | 13.50 |
| Force Constant (Kf) | [ N/Arms ] | 91.68 | 112.27 | 73.43 | 64.11 | 116.59 |
| Back EMF Constant (Ke) | [ V/(m/sec)] | 30.60 | 37.65 | 24.50 | 21.30 | 38.84 |
| Motor Constant | [ N/W^½ ] | 33.5 | 62.0 | 56.4 | 23.4 | 121.0 |
| Electrical Time Constant | [ msec ] | 3.38 | 11.86 | 9.13 | 0.97 | 9.00 |
| POLE Pitch | [ mm ] | 30.0 | 30.0 | 42.0 | 30.0 | 60.0 |
| Normal Force | [ N ] | 1500.0 | 1600.0 | 3225.0 | 0 | 0.0 |
| Weight | [ kg ] | 2.45 | 6.68 | 11 | 1.28 | 34.20 |
