SEOKWANG SHOT MACHINERY

Hoist Hanger Type Shot Machine

Model

Series

Shot Machine

Transaction Process

Please contact the manufacturer/supplier.

Payment

Contact the manufacturer/supplier.

Delivery

Contact the manufacturer/supplier.

Shipment

Contact the manufacturer/supplier.

Origin

Contact the manufacturer/supplier.

Description

서광쇼트기계(주) Hoist Hanger Type Shot Machine SKCH-20/25/30/40/50

서광쇼트기계(주) Hoist Hanger Type Shot Machine SKCH-20/25/30/40/50 1

중량물을 처리하는 기종이며 HOIST CRANE을 이용하여 장입, 장탈하므로 능률적이고 연속 작업을 위해서 Y-Rail, T-Rail, MONO-Tail Type이 있다.

ITEMS/MODEL NO.	SKCH-20	SKCH-25	SKCH-30	SKCH-40	SKCH-50
ET SIZE	□2300×2500H	□2500×3200H	□3050×3800H	□3750×5050H	□4200×6200H
DIMENSION OF WORKPIECE	Ø1800×2000H	Ø2000×2500H	Ø2500×3000H	Ø3000×4000H	Ø3500×5000H
WEIGHT OF WORKPIECE	2000kg	3000kg	5000kg	7000kg	15000kg
IMPELLER UNIT	Ø360×62W	Ø360×62W	Ø360×62W	Ø360×62W	Ø420×76W
IMPELLER MOTOR	15HP×3SET	15HP×4SET	15HP×5SET	15HP×6SET	20HP×6SET
WEIGHT OF ABRASIVE	540kg/min	720kg/min	720kg/min	1080kg/min	1440kg/min
DUST COLLECTOR	80㎥/min	100㎥/min	200㎥/min	250㎥/min	400㎥/min
