Vertical 3 Axis Flow Forming Machine

Model Name

SD-HF

Series

Flowing Forming Machine

Data

Manufacturer information

Press machine manufacturer, High speed press, Transfer press, Knuckle press, Feeder, Machine tools, Gripper and more

Inquiry

Problem with product info?

Update request

Manufacturer

SAMDO PRESS

Product Type

Machine

Brand

SKU

7637

Product Name

Vertical 3 Axis Flow Forming Machine

Model Name

SD-HF, HF-3R-700

Size

Weight

Product Details

Minimize the deformation by lower frame, upper fixed beam and up/down Saddle fix structure
Minimize the deformation and Noise as consist of Main Shaft, Saddle, Tailstock Cast Iron structure
Keep high load and high speed response capacity through control of 3 axis rollers
Minimize the deformation of Saddle as applying 2 ball screws are composed of up/down diagonal And Forming load has improved
Processing accuracy is improving as applying roller LM bearing of up/down 4 sides And straightness of saddle has improved
Large product production possibility through side movements of tailstock

Form Accuracy along Flow Forming Product Size
Diameter (mm)		≤ 100	≤ 250	≤ 400
Final Thickness (mm)		≤ 2	≤ 3	≤ 4
Feature
Roundness (mm)		≤ 0.1	≤ 0.2	≤
Straightness/1000 (mm)		≤ 0.1	≤ 0.15	≤
Radial Thickness accuracy		±0.02	±0.025	±0.04
Axial Thickness accuracy (mm)		±0.02	±0.03	±0.04
External Diameter Surface Roughness After Forming (µm)		≤ 0.4	≤ 0.05	≤ 0.6
Inside Diameter Surface Roughness After Forming (µm)		≤ 0.1	≤ 0.1	≤ 0.15
Item	Unit	Specification
Rim Diameter	mm	Ø 100 ~ Ø 560
Length Blank Thickness	mm	Forward forming : 2000
Length Blank Thickness	mm	Backward forming : 3100
Maximum Speed	rpm	60 ~ 160
Motor Capacity for Spindle	kW	200kW (Inventer)
Motor Capacity for Tailstock	kW	30kW (Servo Motor)
Motor Capacity for Saddle	kW	30kW (Servo Motor)
Motor Capacity for Hydraulic Unit	kW	30kW*2 (Servo Motor)
Spinning Rollers		3 EA
Tailstock	Storke x Thrust Load	550mm x 15,000kgf
Tailstock	Feed / Driving Method	5m/min Servo Motor Control
Saddle	Stroke x Thrust Load	2100mm x 40,000kgf
Saddle	Feed / Driving Method	5m/min Servo Motor Control
Saddle roller	Stroke x Thrust Load	230mm x 40,000kgf
Saddle roller	Feed / Driving Method	5m/min Servo Motor Control
Main Shaft Lockout	Stroke x Thrust Load	110mm x 10,000kgf
Weight	43	Installation Area (mm)
Overall Size	mm	11000 x 6600 x 3500 (Height)
