NAMJOO

Dryer

Model

Series

Transaction Process

Please contact the manufacturer/supplier.

Payment

Contact the manufacturer/supplier.

Delivery

Contact the manufacturer/supplier.

Shipment

Contact the manufacturer/supplier.

Origin

Contact the manufacturer/supplier.

Description

제품설명 description
■ 제약, 식품 화학의 분말, 과립 등의 건조에 사용합니다.
■ 조작이 간편하고 유지관리가 편리합니다.
■ 온수 가열식과 히터 직가열식이 있습니다.
■ 규격 및 용량은 주문에 의하여 제작됩니다.

기술규격서TECHNICAL SPECIFICATION
ㆍORDER MADE (HOT WATER DRYER 1.6㎥)

DIMENSION	Interior W1050xD970xH1600 mm Exterior W 1400xD1120xH2050 mm Door type - one side two door
CAPACITY	Water Temp. 45℃∼90℃ Working Temp. 40℃∼70℃
VOLUME	240L=About 120Kg/Batch
COMPONENT	Main Body Hot Water Tank - 50Lts Tray - STS316L 1.0T Cart - STS304 S/Q Pipe & Angle Blower & heater
ELECTRIC	Control Box Temp. Recorder - 6Point Temp. Controller - 2Set Circulation pump

ㆍORDER MADE (HOT WIND TYPE DRYER 1.7㎥)

DIMENSION	Interior W1080D1000H1600 mm Exterior W1470D1350H1715 mm Door type - one side two door
TEMPERATURE	Max. Temp. 90℃ Working Temp. 45℃∼65℃
VOLUME	3-2 ≒ 200 ∼ 240Lts/batch 3-2 ≒ 100 ∼ 120Kg/Batch
COMPONENT	Main Body Blower & motor Heater Tray - STS304 1.0T Cart - STS304 S/Q Pipe Heating box
ELECTRIC	Control Box Temp. Recorder - 6Point Temp. Controller - 2SetDry timer Electric heater control
