Marion
Model Name
GA6370
Data
Marion GA6370
Manufacturer information
provider logo
MicroinfinitySemi conductor sensor and Navigation sensor manufacturer, Aerospace, Telematics, Motion sensing, Intelligent robot development
Problem with product info?
Update request
Manufacturer
Microinfinity
Brand
-
SKU
43853
Product Name
Marion
Model Name
GA6370
Size
-
Weight
-
Product Details

The GA6370 is a tactical grade GPS/INS integrated navigation system. It uses high performance Ring-Laser Gyroscopes (RLG), accelerometers and a GPS receiver. The GA6370 uses a high order Kalman filter to provide optimum navigation information. It applies various navigation modes that handle the different conditions that may occur during operation. The GA6370 is a highly integrated, compact, light, and fully self-contained navigation system. The data update rate of the system is 100Hz. The GA6370 provides high accuracy real time position, speed and attitude information. The GA6370 can be used in aerospace, land or sea navigation. The GA6370 operates under military environmental conditions and it is being used in medium sized Unmanned Aerial Vehicles (UAVs).



ㆍGPS/INS integrated navigation system
ㆍOptimized 15th order kalman filter
ㆍFast start-up and fully self-contained
ㆍLow power consumption
ㆍCompact and rugged package



Specification

Performance Input range Rate ± 1000 ˚/sec
Acceleration ± 37G
Accuracy Position 3 m CEP (with GPS)
Velocity 0.5 m/s RMS (with GPS)
Heading, Roll, Pitch 1 ˚, 0.1 ˚, 0.1 ˚ RMS (with GPS)
Gyro drift 1 ˚/hr
Update rate 100 Hz
Physical Weight 2.7 kg (including case)
Size (L, W, H) 160 mm X 148 mm X 128 mm
Electrical Power consumption 26 W (nominal)
Input voltage 28 ~ 35 V
Environmental Operating temperature -40 ~ 85 °C
MicroinfinitySemi conductor sensor and Navigation sensor manufacturer, Aerospace, Telematics, Motion sensing, Intelligent robot development
Navigation is the technique of measuring position and attitude of moving objects. In recent years, the necessity of navigation has grown significantly, in the form of harmonized navigation solutions for Unmanned Aerial Vehicles (UAVs) and smart guided missiles, safety gear for vehicles, telemetry systems and intelligent cleaning robots. Other areas as the IT market have also benefited from this technology in fields such as virtual reality, gaming, and smart remote controllers. Microinfinity Co., Ltd. specializes in navigation system technologies and was founded on March 2001 by professionals with over 20 years of research experience in the field of aerospace navigation. The goal of Microinfinity is to create a world where people from various fields can use localization information anywhere, at any time, through navigation technology. Microinfinity was created to be a "Total navigation solution provider" that provides core parts, system planning, and solutions. Microinfinity's mission is to facilitate convenient and comfortable life quality through creative navigation products. To this end, Microinfinity has become a true navigation solution partner by producing the best sensor and system products. Microinfinity owns IP technology that starts from basic sensors to full navigation systems, and is becoming the world leading navigation system company.
