FXC-COMPFO11 COMPONENT signal is receiving a signal designed to be transmitted is converted to FIBER OPTIC.
In addition, the user using the FXC series can be designed by selecting the desired input and output signals.
★INPUT : COMPONENT
★OUTPUT : FIBER OPTIC
-. High speed and long-distance transmisson of tow channels LC-type optical fiber designed
-. 2,000m 2LC Single Mode Fibers.
-. 500m 2LC Multi Mode Fibers.
RESOLUTION | 480i(50/60Hz), 720p(50/59.94/60Hz), 1080i(50/59.94/60Hz), 1080p(50/59.94/60Hz) |
VIDEO BANDWIDTH | 1.65Gbps |
DISTANCE | 2LC Multi Mode : 500m 2LC Single Mode : 2,000m |
POWER | DC 5V/3A, 100~240V |
DIMENSION(mm) | 125 x 120 x 35 |
WEIGHT(Kg) | 0.6 |
ENVIRONMENT | -10°C~60°C / Humidity 80% |
