This product is manufactured by
Master Electronics
Manufacturer information
Master Electronics
Video signal testing equipment manufacturer, Generator, Multi media player and more
Inquiry
How to order
Problem with product info?
Update request
Manufacturer
Master Electronics
Product Type
Machine
Brand
-
SKU
45550
Product Name
Fiber Optic Extender (Box)
Model Name
FXC-FOVID11 (RX)
Size
-
Weight
-
Product Details
FXC-FOVDI11 FIBER OPTIC is receiving a signal designed to be transmitted is converted to S-VIDEO, CVBS signal.
In addition, the user using the FXC series can be designed by selecting the desired input and output signals.
★INPUT : FIBER OPTIC
★OUTPUT : S-VIDEO, CVBS
-. High speed and long-distance transmisson of tow channels LC-type optical fiber designed
-. 2,000m 2LC Single Mode Fibers.
-. 500m 2LC Multi Mode Fibers.
RESOULTION | NTSC, PAL |
DISTANCE | 2LC Multi Mode : 500m 2LC Single Mode : 2,000m |
POWER | DC 5V/3A, 100~240V |
DIMENSION(mm) | 125 x 120 x 35 |
WEIGHT(Kg) | 0.6 |
ENVIRONMENT | -10°C~60°C / Humidity 80% |
