Technical specification
| Maximum film advance | 250 mm (or longer on request) | Power consumption | Below 220V 15Kw or below 380V 13Kw, with vacuum pump equipped |
| Maximum forming depth | 60mm | Pneumatic consumption | 700 liters per minute, 7 bars |
| Bottom film width | 324 ~ 384 mm (width exceeding 384mm for option) | Water consumption | 80 liters per hour, 1 bar |
| Loading area | It depends on the buyer's packaging requirements | Weight | 700 kg |
| Control system | PLC Control / Servo Motor | Production capacity | More than 6 CPM (CPM : Cycles per minute, the number of advances repeated in a minute) |
| Power source | 220V/3P, 380V/4P, 50/60Hz | ||
Standard dimension in mm
