Special Feature
* High-speed cutting of medium or thick plates
* Concentrated cutting heat minimizes thermal deformation
* Novices may also work because of the durability and simple operation
* Built-in self-inspection function of the disorder of the machine
* 220V/380V/440V combined use
|
 Specification  |
||
|
 Output Current  |
 A  |
 3 Phase - 100  |
|
 1 Phase - 80  |
||
|
 Input Voltage  |
 V  |
 220V/380V/440V ± 10%  |
|
 Rated Frequency  |
 Hz  |
 50/60  |
|
 Rated Input  |
 KVA  |
 15.1  |
|
 Rated load Voltage  |
 V  |
 128  |
|
 Output Current range  |
 A  |
 25-100  |
|
 Duty Cycle  |
 %  |
 50  |
|
 Dimension (WxDxH)  |
 W*D*H (m/m)  |
 360 x 623 x 580(360 x 693 x 615)  |
|
 Weight  |
 kg  |
 51  |
※ Product specifications can be changed unexpectedly for product performance improvement.
