Special Feature
* High-speed cutting of thin or medium plates
* The smallest size in the same grade in the country issuitable to field work
* Built-in self-inspection function of the disorder of the machine
* Trans design based on long experiences shows low noise, high cutting performance, and small nozzle abrasion
* Possible single-phase or triple-phase input
|
 Specification  |
|||
|
 MODE  |
 HT-75A II (220V ์ ์ฉ)  |
 HT-75A II (๊ฒธ์ฉ)  |
|
|
 Output Current  |
 A  |
 75  |
 75  |
|
 Input Voltage  |
 V  |
 1 / 3 Phase, 220V ± 10%  |
 1 / 3 Phase, 220V/380V/440V ± 10%  |
|
 Rated Frequency  |
 Hz  |
 50 / 60  |
 50 / 60  |
|
 Rated Input  |
 KVA  |
 10.6  |
 10.6  |
|
 Rated load Voltage  |
 V  |
 112  |
 112  |
|
 Output Current range  |
 A  |
 25-75  |
 25-75  |
|
 Duty Cycle  |
 %  |
 50  |
 50  |
|
 Dimension (WxDxH)  |
 W*D*H (m/m)  |
 263 x 470 x 352  |
 263 x 470 x 352  |
|
 Weight  |
 kg  |
 23.6  |
 24.6  |
โป Product specifications can be changed unexpectedly for product performance improvement.
