Special Feature
* High-speed cutting of thin or medium plates
* The smallest size in the same grade in the country issuitable to field work
* Energy-saving effect and 220V single phase
* Built-in self-inspection function of the disorder of the machine
* Trans design based on long experiences shows low noise, high cutting performance, and small nozzle abrasion
|
 Specification  |
||
|
 Output Current  |
 A  |
 55  |
|
 Input Voltage  |
 V  |
 1 Phase, 220V ± 10%  |
|
 Rated Frequency  |
 Hz  |
 50/60  |
|
 Rated Input  |
 KVA  |
 8.6  |
|
 Rated load Voltage  |
 V  |
 102  |
|
 Output Current range  |
 A  |
 25-55  |
|
 Duty Cycle  |
 %  |
 50  |
|
 Dimension (WxDxH)  |
 W*D*H (m/m)  |
 239 x 487 x 300  |
|
 Weight  |
 kg  |
 19  |
โป Product specifications can be changed unexpectedly for product performance improvement.
