Special Feature
THYRISTOR(SCR) Control
* Weldability : Good weldability is accomplished in all the welding current ranges form minimum current to maximum current with the sustainable control by thyristor.
* Durability : The main trnasformer, the core of welder, is made of good conductive material to show good heat-resistance and durability.
* Economical efficiency : Energy-saving design saves the power during unload of arc.
|
 Specification  |
||
|
 Output Current range  |
 A  |
 500  |
|
 Output Voltage range  |
 V  |
 220V / 380V / 440V ± 10%  |
|
 Input Voltage  |

  |
 3 Phase  |
|
 Input Phase  |
 Hz  |
 50/60  |
|
 Rated Frequency  |
 KVA / KW  |
 33.2 / 30  |
|
 Rated Input  |
 V  |
 42  |
|
 Rated load Voltage  |
 A  |
 50~500  |
|
 No load Voltage  |
 V  |
 14~42  |
|
 Duty Cycle  |
 %  |
 80  |
|
 Control  |

  |
 THYRISTOR (SCR) ๋ฐฉ์  |
|
 Dimension (WxDxH)  |
 W*D*H (m/m)  |
 515 x 715 x 920  |
|
 Weight  |
 kg  |
 210  |
โป Product specifications can be changed unexpectedly for product performance improvement.
