Welding M/C manufacturer, DC arc welder, TIG, Argon, CO2, MAG welder, Plasma cutter, Mixed type gas welder and more
Special Feature
* High-speed welding and sustainable arc
* Reduced generation of spatter
* Energy Saving
* Small size and light weight
* Improved quality and work efficiency with high-speed welding
* Sustainable weldability
* Beautiful welding beads / * Sharp design / * 220V/380V/440V combined use
|
 Specification  |
||
|
 Output Current range  |
 A  |
 50~500  |
|
 Output Voltage range  |
 V  |
 14~42  |
|
 Input Voltage  |
 V  |
 220V / 380V / 440V ± 10%  |
|
 Input Phase  |

  |
 3 Phase  |
|
 Rated Frequency  |
 Hz  |
 50/60  |
|
 Rated Input  |
 KVA  |
 20.9  |
|
 Rated load Voltage  |
 V  |
 42  |
|
 No load Voltage  |
 V  |
 68  |
|
 Duty Cycle  |
 %  |
 60  |
|
 Controler  |

  |
 I.G.B.T  |
|
 Dimension (WxDxH)  |
 W*D*H (m/m)  |
 360 x 623 x 580(360 x 693 x 615)  |
|
 Weight  |
 kg  |
 56  |
※ Product specifications can be changed unexpectedly for product performance improvement.
