Special Feature
* Possible welding of all kinds of meatais using one machine
* Design for convenient use
* High-quality welding using pulse function
* Built-in remote control function
* Built-in self-inspection function of the disorder of the machine
* Possible single-phase or triple-phase input
* 220V/380V/440V combined use
|
 Specification  |
|||
|
 Process  |

  |
 TIG  |
 STICK  |
|
 Output Current  |
 A  |
 3 Phase - 500  |
 290  |
|
 1 Phase - 320  |
|||
|
 Input Voltage  |
 V  |
 220V / 380V / 440V ± 10%  |
|
|
 Rated Frequency  |
 Hz  |
 50/60  |
|
|
 Rated Input  |
 KVA / KW  |
 19.1  |
|
|
 Rated load Voltage  |
 V  |
 30  |
|
|
 No load Voltage  |
 V  |
 67  |
|
|
 Duty Cycle  |
 %  |
 50  |
|
|
 Output Current range  |
 A  |
 10~ 500  |
 15 ~ 290  |
|
 Gas After flow  |
 sec  |
 0.1 ~ 10  |
|
|
 Down Slope  |
 sec  |
 0.1 ~ 10  |
|
|
 Arc Spot  |
 sec  |
 0.1 ~ 10  |
|
|
 Pluse Frequency  |
 Hz  |
 LOW : 0.5~15, HI : 15~500  |
|
|
 Pluse Width  |
 %  |
 15 ~ 85  |
|
|
 Crater control  |

  |
 Off, On, Repeat  |
|
|
 Dimension (WxDxH)  |
 mm  |
 380 x 623 x 580(380 x 693 x 615)  |
|
|
 Weight  |
 kg  |
 56  |
|
※ Product specifications can be changed unexpectedly for product performance improvement.
※ Remote control is separate way option.
