Welding M/C manufacturer, DC arc welder, TIG, Argon, CO2, MAG welder, Plasma cutter, Mixed type gas welder and more
Special Feature
* Suitable to thin or medium plate
* Use of 4.5Ø welding rod
* Firm design for mobile use
* Built-in function to prevent arc-discontinuation
* Built-in electric shock prevention function
* Single-phase input
|
 Specification  |
|||||||||||||||||||||||
|
 MODE  |
 SHARP-230A II  |
||||||||||||||||||||||
| Output Current | A | 230 | |||||||||||||||||||||
|
 Input Voltage  |
V |
 1 Phase 220V ± 10%  |
|||||||||||||||||||||
|
 Rated Frequency  |
Hz |
 50 / 60  |
|||||||||||||||||||||
|
 Rated Input  |
KVA |
 9.2  |
|||||||||||||||||||||
|
 Rated load Voltage  |
 V  |
 29.2  |
|||||||||||||||||||||
|
 Duty Cycle  |
 %  |
 50  |
|||||||||||||||||||||
|
 Dimension (WxDxH)  |
 mm  |
 239 x 445 x 277  |
|||||||||||||||||||||
|
 Weight  |
 kg  |
 17.4  |
|||||||||||||||||||||
※ Product specifications can be changed unexpectedly for product performance improvement.
