* Stainless mesh conveyer : It conveys more exact amount of fertilizer or sand and is more durable than rubber conveyors
* Stainless Steel parts : A hopper, feeding conveyer belt, spinner discs, vanes and prevent plate
* The speed of spinner disc can be controlled by a valve
* Ground driven : As the fertilizer that fed into spinner disc varies according to the rotating speed of a wheel, it is possible to spread evenly regardless of the speed of a vehicle (As a result, the faster a vehicle run the larger amiunt of fertilzier is fed, the slower a vehicle run the smaller amont of fertilizer is fed)
* Hydraulic automatic system : The operation of conveyer and that of fertilizer outlet is linked both are controlled by one hydraulic lever
* Relief valve : Durability of htdraulic motor for spinner disc is improved by installing relief valve (It controls the pressure that occurred when the motor stops and overload)
* Hydraulic outlet shutter : The outlet size can be controlled and fixed as you want
* Windows to see inside fertilizer
* Safety grill : It is optional
* Twin side conveyors : It is optional for orchard
* Hydraulic driven system : optional
SPECIFICATION
|
MODEL
|
VIKING-2000
|
VIKING-3000
|
VIKING-3000L
|
|
HOPPER CAPACITY
|
1.8㎥
|
2.7㎥
|
2.7㎥
|
|
NOMINAL CAPACITY
|
2Ton
|
3Ton
|
3Ton
|
|
WIDTH(mm)
|
1800
|
1800
|
1800
|
|
HEIGHT(mm)
|
1570
|
1795
|
1625
|
|
FEED MESH CHAIN WIDTH(mm)
|
500
|
500
|
500
|
|
DISC SIZE(mm)
|
600
|
600
|
600
|
|
AXLES
|
SINGLE
|
SINGLE
|
SINGLE
|
|
TIRES
|
11.5/80-15.3 x 2
|
11.5/80-15.3 x 2
|
11.5/80-15.3 x 2
|
|
TYPE
|
PULL TYPE
|
PULL TYPE
|
PULL TYPE
|
|
POWER
|
GROUND DRIVEN /HYDRAULIC
|
GROUND DRIVEN /HYDRAULIC
|
GROUND DRIVEN /HYDRAULIC
|
