Manufacturer
GOT
Product Type
Machine
Brand
-
SKU
122888
Product Name
Marine Engine
Model Name
G6HD500
Size
-
Weight
-
Product Details
PERFORMANCE GRAPH
GENERAL SPECIFICATION
| General Specification | ||
|---|---|---|
| Engine model | G6HD500 | |
| Type | 4 CYCLE TURBOCHARGED WITH INTERCOOLER | |
| RATED OUTPUT (WITHOUT FAN) | 500 PS / 2100 RPM | |
| MAX TORQUE | 216 kg.m / 1200 RPM | |
| NO. OF CYL & ARRANGEMENT | 6-IN LINE | |
| COMBUSTION CHAMBER TYPE | DIRECT INJECTION | |
| BORE X STROKE | 130 mm x 155 mm | |
| TOTAL PITON DISPLACEMENT | 11,149 cc | |
| COMPRETION RATIO | 17.2:1 | |
| ROTATION | COUNTER-CLOCKWISE ROTATION AS VIEWED FROM FLYWHEEL SIDE | |
| FIRING ORDER | 1-5-3-6-2-4 | |
| WEIGHT DRY | 1480 Kg(Approx) | |
| DIMENSION | LENGTH | 1391 mm |
| WIDTH | 849 mm | |
| HEIGHT | 1320 mm | |
| Gearbox | DMT140H | 1.97~3.46 |
※Weight : Transmission is included
Marine Engine & Generator, Marine Propulsion System for small & mid sized vessels
G.O.T(Golden Ocean Technology) is a technology-oriented enterprise, which is specialized in developing and manufacturing marine diesel engine and propulsion systems for small & medium sized vessels. Our major products are marine diesel engines, generators.
And also gasoline outboard engines, new type of stern drive designed ourselves are ready to commercialize on the market.
We will do our best all the time to provide our customers with the best satisfaction, profits with high quality products & the best services.
