Power Transmission Belt, Conveyor Belt, Rubber Track, Rubber Pad
Features
| Construction | Functions | Materials |
|---|---|---|
| ① Rear fabric | Protection of tension member | CR, HNBR |
| ② Tension member | Primary material for transferring power | Glass Fiber |
| ③ Teeth rubber | Tension member protection and belt shape maintaining | CR, HNBR |
| ④ Bottom fabric | Belt and teeth maintaining | Nylon |
CR : Chloroprene Rubber / HNBR : Hydrogenated Nitrile Butadiene Rubber
Measure of section
| Pitch(㎜) | Rib Height(㎜) | Height(㎜) | |
|---|---|---|---|
| MXL Type | 2.032 | 0.51 | 1.14 |
| XL Type | 5.08 | 1.25 | 2.30 |
| L Type | 9.525 | 1.90 | 3.60 |
| H Type | 12.70 | 2.29 | 4.30 |
| S5M Type | 5.00 | 1.91 | 3.61 |
| S8M Type | 8.00 | 3.89 | 5.20 |
| S14M Type | 14.00 | 5.30 | 10.20 |
