Rotary Gas Meter
Model Name
-
Size
-
Weight
-
Product Details
| G16 | G25 | G40 | G65 | G100 | G160 | G250 | G400 | |
| DN (mm) | 50 | 50/80 | 80 | 100 | ||||
| Pressure( Bar ) | 16 | |||||||
| Qmin m³/h | 0.3 | 0.3 | 0.4 | 0.6 | 1.0 | 1.6 | 2.5 | 4.0 |
| Qmax m³/h | 25 | 40 | 65 | 100 | 160 | 250 | 400 | 650 |
| T.D.R | 80 : 1 | 160 : 1 | ||||||
| Error Qmax - QT | +/- 1% | |||||||
| Qt - QMIN | +/- 2.0% | |||||||
| Gas | LNG, LPG | |||||||
| LF Pulser | Basically settled | |||||||
| HF | OPTION | |||||||
| ROTOR materials | Aluminium (AI) | |||||||
| BODY materials | Aluminium (AI) | |||||||
| 0DN | ||||||||
| Approval | OIML, PTB, EEC, ISO, DVGW | |||||||
| Feature | Double Body Type, Easy to maintain, Easy to put an oil | |||||||
| DN | G-Size | A | B | L | K | N | Weight | |
| MM | mm | mm | mm | mm | mm | AI | ||
| 40 | G16,25 | 165 | 171 | 277 | 110 | 4 | 10 | - |
| G40 | 184 | 171 | 296 | 110 | 4 | 12 | - | |
| 50 | G40 | 184 | 171 | 296 | 125 | 4 | 12 | - |
| G65 | 225 | 171 | 337 | 125 | 4 | 14 | 25 | |
| 80 | G65 | 225 | 171 | 337 | 160 | 8 | 14 | 25 |
| G100,G65 | 295 | 171 | 407 | 160 | 8 | 19 | 31 | |
| G100 | 249 | 240 | 356 | 160 | 8 | 25 | 26 | |
| G160 | 314 | 240 | 421 | 160 | 8 | 31 | 68 | |
| 100 | G250,G400 | 439 | 240 | 546 | 160 | 8 | 42 | 92 |
