Overview
- Summary
- DAESUNG SWITCH is a specialized manufacturer of conveyor safety devices, focusing on the development and supply of various switch products for industrial safetyDAESUNG SWITCH is a specialized manufacturer of conveyor safety devices, focusing on the development and supply of various switch products for industrial safety
- Key Products/Technologies
- PULL CORD SWITCH: An emergency stop safety switch for conveyor lines. Models include DBSS-10, DBSS-10EX, DBSS10EX-UH, DBSS-10L. The DBSS-10EX model features SPDTx2EA contacts, 8±1Kg pull force, 3.62KG weight, PF 3/4"x 2EA cable entry, explosion-proof capabilities (EX tD A21 T85 IP67, EX DP II IP67), and CE (IEC 60947-5-1) certification. The DBSS10EX-UH model is an upper cover type with KOSHA certificationPULL CORD SWITCH: An emergency stop safety switch for conveyor lines. Models include DBSS-10, DBSS-10EX, DBSS10EX-UH, DBSS-10L. The DBSS-10EX model features SPDTx2EA contacts, 8±1Kg pull force, 3.62KG weight, PF 3/4"x 2EA cable entry, explosion-proof capabilities (EX tD A21 T85 IP67, EX DP II IP67), and CE (IEC 60947-5-1) certification. The DBSS10EX-UH model is an upper cover type with KOSHA certification
- BELT ALIGNMENT SWITCH: A switch designed to detect conveyor belt misalignment and ensure safety. Models include DBSS-20, DBSS-20EX, DBSS-20EX-U. The DBSS-20EX model features a contact capacity of 15A 125VAC, 10A 250AC, 5A 48VDC, explosion-proof capabilities (EX tD A 21/A22 T85 IP 66/67), UL and KOSHA certifications, SPDT x 2EA contacts, operating angles of 25 degrees (trip) and 35 degrees (stop), 4.4KG weight, and PF 3/4" x 2EA cable entryBELT ALIGNMENT SWITCH: A switch designed to detect conveyor belt misalignment and ensure safety. Models include DBSS-20, DBSS-20EX, DBSS-20EX-U. The DBSS-20EX model features a contact capacity of 15A 125VAC, 10A 250AC, 5A 48VDC, explosion-proof capabilities (EX tD A 21/A22 T85 IP 66/67), UL and KOSHA certifications, SPDT x 2EA contacts, operating angles of 25 degrees (trip) and 35 degrees (stop), 4.4KG weight, and PF 3/4" x 2EA cable entry
- SPEED SWITCH: A switch that detects conveyor belt speed, providing alerts and stop signals for overspeed or underspeed conditions. Models include DBSS-40EX-P, DBSS-EX-W. The DBSS-EX-W model features a contact capacity of 10A 250VAC, 15A 125VAC, explosion-proof capabilities (EX tD A22 T85 IP66), KC s certification, SPDTx2EA contacts, a control speed range of 0~9999 RPM, ON/OFF time delays of 0~30 seconds, AC 85-250V free voltage power (option: DC 24V), and an accuracy of 0.0001%SPEED SWITCH: A switch that detects conveyor belt speed, providing alerts and stop signals for overspeed or underspeed conditions. Models include DBSS-40EX-P, DBSS-EX-W. The DBSS-EX-W model features a contact capacity of 10A 250VAC, 15A 125VAC, explosion-proof capabilities (EX tD A22 T85 IP66), KC s certification, SPDTx2EA contacts, a control speed range of 0~9999 RPM, ON/OFF time delays of 0~30 seconds, AC 85-250V free voltage power (option: DC 24V), and an accuracy of 0.0001%
- TILT (CHUTE) SWITCH: A switch for detecting the presence or level of material in chutes or storage bins. Model DCS-30EX availableTILT (CHUTE) SWITCH: A switch for detecting the presence or level of material in chutes or storage bins. Model DCS-30EX available
- LIMIT SWITCH: A switch that detects when a machine part reaches a specific position. Model DS-R110EX available. It features a contact capacity of 10A 250VAC, 5A 48VDC, heavy-duty type, explosion-proof capabilities (Ex tD A21/22 IP66/67 T85), 2NO, 2NC 2COM contacts, 2-cam auto reset and free cam adjustment functions, and PF 3/4″ cable entryLIMIT SWITCH: A switch that detects when a machine part reaches a specific position. Model DS-R110EX available. It features a contact capacity of 10A 250VAC, 5A 48VDC, heavy-duty type, explosion-proof capabilities (Ex tD A21/22 IP66/67 T85), 2NO, 2NC 2COM contacts, 2-cam auto reset and free cam adjustment functions, and PF 3/4″ cable entry
- Core Advantages
- Specialized expertise in conveyor safety devices, offering a deep understanding of specific industrial safety requirements and customized solutionsSpecialized expertise in conveyor safety devices, offering a deep understanding of specific industrial safety requirements and customized solutions
- A diverse product range of conveyor safety switches, providing a wide selection to meet various customer environments and needsA diverse product range of conveyor safety switches, providing a wide selection to meet various customer environments and needs
- Availability of explosion-proof product lines, ensuring safe operation in hazardous industrial environments with explosion risksAvailability of explosion-proof product lines, ensuring safe operation in hazardous industrial environments with explosion risks
- Attainment of major domestic and international safety certifications such as KOSHA, UL, CE, and KC s, validating product reliability and safetyAttainment of major domestic and international safety certifications such as KOSHA, UL, CE, and KC s, validating product reliability and safety
- Precise sensing and control technology, supporting the prevention of conveyor system malfunctions and efficient operationsPrecise sensing and control technology, supporting the prevention of conveyor system malfunctions and efficient operations
- Robust design and use of high-quality components, ensuring excellent durability and long-term stability even in harsh industrial conditionsRobust design and use of high-quality components, ensuring excellent durability and long-term stability even in harsh industrial conditions
- Target Industries
- Mining and Quarrying IndustryMining and Quarrying Industry
- Cement and Aggregate IndustryCement and Aggregate Industry
- Iron and Steel Manufacturing and Metal Processing IndustryIron and Steel Manufacturing and Metal Processing Industry
- Power Plants and Energy IndustryPower Plants and Energy Industry
- Ports and Logistics TerminalsPorts and Logistics Terminals
- Chemical and Petrochemical IndustryChemical and Petrochemical Industry
- Food Processing and Feed IndustryFood Processing and Feed Industry
- Recycling and Waste Management IndustryRecycling and Waste Management Industry
- Major Markets
- --
- Certifications/Patents
- KOSHA Certification: PULL CORD SWITCH (DBSS10EX-UH), BELT ALIGNMENT SWITCH (DBSS-20EX) modelsKOSHA Certification: PULL CORD SWITCH (DBSS10EX-UH), BELT ALIGNMENT SWITCH (DBSS-20EX) models
- CE (IEC 60947-5-1) Certification: PULL CORD SWITCH (DBSS-10EX) modelCE (IEC 60947-5-1) Certification: PULL CORD SWITCH (DBSS-10EX) model
- UL Certification: BELT ALIGNMENT SWITCH (DBSS-20EX) modelUL Certification: BELT ALIGNMENT SWITCH (DBSS-20EX) model
- KC s Certification: SPEED SWITCH (DBSS-EX-W) modelKC s Certification: SPEED SWITCH (DBSS-EX-W) model
Introduction
Location
8 Muhak-ro 21beon-gil, Suyeong-gu, Busan, South Korea
