- Displacement : 1540 cc/rev.

- Pressure : Max. 30 Bar

- Viscosity : Max. 1,000,000 cp

- Temperature : Max. 200 ℃

Dimensions

A: 180 mm, B : 210mm, C: 320mm, D: 115mm, E: 115mm, F: 57mm, G: 86mm, H: 200mm, I-1: 48mm, I-2: 224mm, J: 70mm, K: 52mm, L-1: 443mm, L-2: 619mm, M: 373mm, N: 16x12, O: 265mm, Diameter for 4 Holes of Base: 17mm

Applications : Beverage, Dairy, Pharmaceutical, Paste, etc.
