각종 자동차 부품을 연마 가공하는 기계는 여러 종류가 있습니다. 크게 두 종류로 나누어지는데 페이퍼로 가공하는 Lapping Machine과 지석으로 가공하는 Superfinishing Machine이 있습니다.
Superfinishing Machine (Thrufeed Type)
DSF-500
DSF-900
Workpieces | OD (mm) | Ø8 ~ Ø40 | Ø8 ~ Ø40 |
Length (mm) | 100 ~ 640 | 100 ~ 640 | |
Ra(㎛) | 0.05 | 0.05 | |
Facilities | Stone Guide Type | Air Type | Hydraulic Type |
Coolant Oil | Non-soluble oil | Non-soluble oil | |
Oscillation | Type | Motor | Motor |
Support | Air Bearing | Ball Strocke | |
Stroke (mm) | 1 (1.5, 2) | 1 (1.5, 2) | |
FPM | 1100 ~ 2500 | 450 ~ 2500 | |
Roller | OD (mm) | 90 | 125 |
Length (mm) | 500 | 900 | |
Traversing angle(°) | 1 | 2 | |
RPM | 100 ~ 400 | 100 ~ 450 |
Polishing Machine
The DPO Series is a machine for machining the outer diameter of small parts such as Support Input Shaft.
Small Lapping Machine
The DSL series is a machine that processes the input / output / manual shaft outer diameter of the transmission using tape.
Small Lapping Machine
The DSL series is a machine that processes the input / output / manual shaft outer diameter of the transmission using tape.
