Overview
- Summary
- Established in 1996, Daedong Index Co., Ltd. is a specialized manufacturer of index drives, shafts, flanges, and table types, key components for machine automation. The company has built a full line-up system for cam-type index drives optimized for high-speed, high-precision, and high-load environments, based on a technical partnership with Italy's COLOMBO. Its capabilities include continuous product development and quality management to supply essential devices for industrial sites.Established in 1996, Daedong Index Co., Ltd. is a specialized manufacturer of index drives, shafts, flanges, and table types, key components for machine automation. The company has built a full line-up system for cam-type index drives optimized for high-speed, high-precision, and high-load environments, based on a technical partnership with Italy's COLOMBO. Its capabilities include continuous product development and quality management to supply essential devices for industrial sites.
- Key Products/Technologies
- CF2 NC ROTARY TABLE: Rotary table models including DRC 170, DRC 200, DRC 250, and DRC 320.CF2 NC ROTARY TABLE: Rotary table models including DRC 170, DRC 200, DRC 250, and DRC 320.
- CF2 RSD (Roller Servo Drive): A motion control unit based on a servo system, achieving Zero-Backlash through the application of roller gear cams. It boasts excellent positioning accuracy of 40 arc.sec or less and repeatability of ±5 arc.sec or less, making it a high-quality, high-reliability product.CF2 RSD (Roller Servo Drive): A motion control unit based on a servo system, achieving Zero-Backlash through the application of roller gear cams. It boasts excellent positioning accuracy of 40 arc.sec or less and repeatability of ±5 arc.sec or less, making it a high-quality, high-reliability product.
- CF3 Parallel Index Drive: Composed of a parallel cam and a divided plate, with pre-load applied to the follower rollers to suppress backlash and vibration. It eliminates the need for a separate brake during stops. A diverse lineup of models from CF-65P to CF-400P.CF3 Parallel Index Drive: Composed of a parallel cam and a divided plate, with pre-load applied to the follower rollers to suppress backlash and vibration. It eliminates the need for a separate brake during stops. A diverse lineup of models from CF-65P to CF-400P.
- CF4 Roller Gear Index Drive (T-type, S/F-type, OU-type, DLPP-type, OSU/OSN-type): A roller gear index drive composed of a globoidal cam, cam followers, and a turret.CF4 Roller Gear Index Drive (T-type, S/F-type, OU-type, DLPP-type, OSU/OSN-type): A roller gear index drive composed of a globoidal cam, cam followers, and a turret.
- CF4 T-type (Table Type): Offers various cam curves, such as modified sine for high-speed and medium-heavy loads. Designed for a long lifespan of over 10,000 hours with only oil changes and capable of installation on six faces.CF4 T-type (Table Type): Offers various cam curves, such as modified sine for high-speed and medium-heavy loads. Designed for a long lifespan of over 10,000 hours with only oil changes and capable of installation on six faces.
- CF4 S/F-type (Shaft/Flange Type): Features pre-loaded cam followers on the taper rib of the roller gear cam, enabling backlash-free rolling contact power transmission. Characterized by low friction loss, excellent wear resistance, and high precision with a standard indexing accuracy of ±30 seconds.CF4 S/F-type (Shaft/Flange Type): Features pre-loaded cam followers on the taper rib of the roller gear cam, enabling backlash-free rolling contact power transmission. Characterized by low friction loss, excellent wear resistance, and high precision with a standard indexing accuracy of ±30 seconds.
- CF4 OU (Oscillating Unit) Type: An automatic work feeding device utilizing an oscillating roller gear cam. It provides oscillation from 15° to 360° with a return to the initial position cycle, offering broad timing chart flexibility.CF4 OU (Oscillating Unit) Type: An automatic work feeding device utilizing an oscillating roller gear cam. It provides oscillation from 15° to 360° with a return to the initial position cycle, offering broad timing chart flexibility.
- CF4 DLPP (Daedong Linear Pick & Place) Type: A compact and slim linear pick & place type achieving high-speed operation and precise positioning. It applies two roller gear cams for horizontal strokes of 10-200mm and vertical strokes of 10-60mm. It boasts high stroke precision of 0.02mm and a maximum speed of 0.5s/pc.CF4 DLPP (Daedong Linear Pick & Place) Type: A compact and slim linear pick & place type achieving high-speed operation and precise positioning. It applies two roller gear cams for horizontal strokes of 10-200mm and vertical strokes of 10-60mm. It boasts high stroke precision of 0.02mm and a maximum speed of 0.5s/pc.
- CF4 OSU/OSN (Oscillating Special Unit): An automatic work feeding device using an oscillating roller gear cam and a rising/falling groove cam. It is characterized by high speed, accurate positioning precision, high productivity, and cost-effectiveness.CF4 OSU/OSN (Oscillating Special Unit): An automatic work feeding device using an oscillating roller gear cam and a rising/falling groove cam. It is characterized by high speed, accurate positioning precision, high productivity, and cost-effectiveness.
- CF5 DBR (BARREL GEAR INDEX DRIVE): A product line of barrel gear index drives.CF5 DBR (BARREL GEAR INDEX DRIVE): A product line of barrel gear index drives.
- Power Lock, AIR CLUTCH & BREAK UNIT, TORQUE LIMITER, CUSTOM CAM: A range of products related to machine automation and power transmission, beyond just index drives.Power Lock, AIR CLUTCH & BREAK UNIT, TORQUE LIMITER, CUSTOM CAM: A range of products related to machine automation and power transmission, beyond just index drives.
- Core Advantages
- A full line-up system across all types of index drives, providing customized solutions suitable for various functions, applications, and forms in diverse industrial settings.A full line-up system across all types of index drives, providing customized solutions suitable for various functions, applications, and forms in diverse industrial settings.
- Acquisition of advanced technology through a technical partnership with Italy's COLOMBO, combined with proprietary product development and quality management expertise accumulated since its establishment in 1996.Acquisition of advanced technology through a technical partnership with Italy's COLOMBO, combined with proprietary product development and quality management expertise accumulated since its establishment in 1996.
- Recognized technical prowess in cam-type index drives, ensuring high speed, precision, and reliability in high-load environments. Achievement of Zero-Backlash and high positioning accuracy.Recognized technical prowess in cam-type index drives, ensuring high speed, precision, and reliability in high-load environments. Achievement of Zero-Backlash and high positioning accuracy.
- Technological innovation through the development of patented products like the Ball Index Drive and One-Cam Parallel Index, leading to enhanced performance, miniaturization, and cost reduction. Strengthened R&D capabilities through investment in advanced equipment such as DMG 5-axis machining centers.Technological innovation through the development of patented products like the Ball Index Drive and One-Cam Parallel Index, leading to enhanced performance, miniaturization, and cost reduction. Strengthened R&D capabilities through investment in advanced equipment such as DMG 5-axis machining centers.
- Proven technical capability and market position as a major supplier to leading equipment manufacturers in the rapidly growing secondary battery industry, including LG Chem, Samsung SDI, and SK Innovation.Proven technical capability and market position as a major supplier to leading equipment manufacturers in the rapidly growing secondary battery industry, including LG Chem, Samsung SDI, and SK Innovation.
- Contribution to reducing the lifecycle costs of automation systems through products designed for long lifespan and minimal maintenance requirements.Contribution to reducing the lifecycle costs of automation systems through products designed for long lifespan and minimal maintenance requirements.
- Target Industrie
- General machine automation industryGeneral machine automation industry
- Secondary battery (battery) manufacturing industry (equipment related to LG Chem, Samsung SDI, SK Innovation)Secondary battery (battery) manufacturing industry (equipment related to LG Chem, Samsung SDI, SK Innovation)
- Grinding devicesGrinding devices
- Conveying robots and transfer equipmentConveying robots and transfer equipment
- Large welding machinesLarge welding machines
- Solar devicesSolar devices
- LED sorting machinesLED sorting machines
- Cleaning machines, processing machines, filling machines, winding machines, packaging machines, presses, machine toolsCleaning machines, processing machines, filling machines, winding machines, packaging machines, presses, machine tools
- Major Markets
- Japan, China (indirect export via LG Chem projects)Japan, China (indirect export via LG Chem projects)
- Europe (indirect export via LG Chem projects)Europe (indirect export via LG Chem projects)
- United States (indirect export via LG Chem projects)United States (indirect export via LG Chem projects)
- Certifications/Patents
- Patent registration for rotary table fixing device (October 2017)Patent registration for rotary table fixing device (October 2017)
- Selected for the 10th Korea Excellent Patent Award in the Machinery category (May 2016)Selected for the 10th Korea Excellent Patent Award in the Machinery category (May 2016)
- Patent registration for Ball Index and Single Cam Parallel Index (October 2015)Patent registration for Ball Index and Single Cam Parallel Index (October 2015)
- INNO-BIZ (Technology Innovation Small and Medium Business) certification (February 2013)INNO-BIZ (Technology Innovation Small and Medium Business) certification (February 2013)
- Designated as a National Root CompanyDesignated as a National Root Company
- Development of rotary tables for machine tools with repeatability of ±5 seconds and indexing accuracy of ±10 seconds through DRC Rotary Table research activities.Development of rotary tables for machine tools with repeatability of ±5 seconds and indexing accuracy of ±10 seconds through DRC Rotary Table research activities.
- Possession of patents for Ball Index Drive and One-Cam Parallel Gear Index Drive.Possession of patents for Ball Index Drive and One-Cam Parallel Gear Index Drive.
- Possession of a patent for a motion control brake device.Possession of a patent for a motion control brake device.
Introduction
Key Products
Location
161 Secheon-ro 1-gil, Dasa-eup, Dalseong-gun, Daegu, South Korea
