● Rating : 250V 10A
● Insulation Resistance : More Than 1000MΩ DC 500V
● Withstand Voltage : AC2000V Per Minute
● Wire Size / Range : AWG18~26
● Maximum Acceptable Temperature : -40°C ~ +85°C
A-B Dimension
|
P |
22 |
38 |
|||
|
A±0.8 |
92.4 |
153.4 |
|||
|
B±0.8 |
76.2 |
137.16 |
|||
|
|
|
|
No |
Component Part |
Material |
Standard |
Plated |
Remark |
|
1 |
Frame |
P.B.T. |
UL94V-0 |
- |
Ivory |
|
2 |
Base |
P.B.T. |
UL94V-0 |
- |
- |
|
3 |
Terminal #1 |
BRASS |
C2680R |
Au |
- |
|
4 |
Terminal #2 |
BRASS |
C2680R |
Au |
- |
|
5 |
Terminal #3 |
PHOSPHOR BRONZE |
C5210 |
Au |
- |
|
6 |
Terminal #4 |
PHOSPHOR BRONZE |
C5210 |
Au |
- |
|
7 |
Screw |
SWCH10AL |
- |
- |
M3*7 |
|
8 |
Washer |
SPCC |
- |
Ni |
□6 * 6 |
|
9 |
Lock Screw |
SWCH10A |
- |
Black Coloring |
M3 * 9.5 |
|
10 |
E-Ring |
SUP |
- |
Ni |
Ø5(Internal Diameter Ø2) |
|
11 |
Insert Nut |
BRASS |
- |
- |
M3 |
|
12 |
Hexagonal Nut |
SWCH10A |
- |
- |
M3 |
