AMP ALL

AMP ALL

Bone Densitometer

Model

Series

Bone Densitometer


Transaction Process

Please contact Komachine.

Payment

Please contact Komachine.

Delivery

Please contact Komachine.

Shipment

Please contact Komachine.

Origin

Please contact Komachine.


Description

Overview

The osteo Checker measure a bone mineral density (BMD) of forearm, calcaneus and grows plate. It is BMD measurement method to show high resolution images after scanning entire measurement area.

AMP ALL Bone Densitometer Osteo Checker


Features

X-ray systemPeripheral DXA (Dual energy X-ray Absorptionmetry)
Scan sitesCalcaneus, Foream, Epiphyseal plate
Weight18.5KG / 30KG (Measuring)




Specification

System
Scanning methodCone beam
Performance
X-ray sourceStationary anode X ray tube
X-ray detectorCCD detector
Reproducibility≤ 5% C.V.
X-ray characteristic
Power100 ~ 120 VAC. 50~60 Hz/220 ~ 240 VAC. 50 ~ 60 Hz
Operating temperature10 ~ 35℃
Relative humidity30 ~ 75 %
Minimum PC requirements
Operating systemWindows XP, Windows 7
CPUMin.2GHz
MemoryMin.4GB
Storage40GB
Communication portUSB 1.1 or higher
Display1920 x 1080 pixel

Download

Catalog-AMP All-Osteo Checker
